Name of Each Section

Tg0869-PM-OM0305-001 19

Multi-Layer Tray Feeder (FP-5022R)

Grips of Magazine

Magazine (MG-5050R)

Magazine Door

Grip of Magazine

Grip

Magazine Door Fixture

Grip of Magazine

Tray Fixing Metal (MF-5050R)

Roller

Anchor Bolt

Lever

Clamp Claw

Pallet (MP-5050)

Front

Back

Operation Monitor (Touch Screen)

Elevator

Center Cover

Upper Door

Lower Door

[UPPER DOOR ELECTRO-

MAGNETIC LOCK] Switch

[U READY] Button

[LOWER DOOR ELECTRO-

MAGNETIC LOCK] Switch

[L READY] Button

0305-001 200305-001 20 Tg0869-PM-OM

Tg0869-PM-OM

The following precautions are particularly important for safe use of this

device. Read and understand these precautions carefully for safe use of

the device.

Refer to "About Precaution Labels" for description of symbols.

1. Basic Precautions

1.1 Safety Check before Powering

• Make sure that no person (or any part of a person's body or

clothing) or other thing touches any moving part of the device.

After careful safety check, power on and start up the device.

Safety Check around the Device

0305-001 21

Compulsion

Safety Check

Safety Precautions

1. Basic Precautions
