Tg0869-PM-OM 5.9 Install the device somewhere where there is no obstacle • For easy maintenance, install the device only where there is no obstacle. • • • • • Dangers if installed where there are obstacles • The device m…

Tg0869-PM-OM

0305-001 52

5.8 Install the device horizontally using a level

• Install the device horizontally using a level.

••

• Dangers caused by the device not being

installed horizontally

• The device might fall due to vibration during an earthquake.

CAUTION

Using a Level

CAUTION

Example: Falling due to Inadequate Strength of Floor

Damage

5.8 Install the device horizontally using a level

Tg0869-PM-OM

5.9 Install the device somewhere where there is no

obstacle

• For easy maintenance, install the device only where there is no

obstacle.

••

• Dangers if installed where there are obstacles

• The device might bump into one of the surrounding obstacles,

with resultant damage.

0305-001 53

Install the device where there is no obstacle

Example: An obstacle collides with the device.

CAUTION

Damage

CAUTION

5.9 Install the device somewhere where there is no obstacle

Tg0869-PM-OM

0305-001 54
