Machine System >> Editing Production Programs On the Machine
SYS-CP842-1.0E 4-71
Vision Type Editing Screen
The vision type can be edited from this screen. For vision type details, refer to the
SMD3 Operation Manual.
Screen Button Explanations
A. [Sequence No.]: Switches to the sequence search screen.
B. [Vision Type]: Changes the vision processing unit’s “vision number”
(PTPVICVT) which is specified in the production program’s
part shape data (VISION).
Setting examples:
10: Square chips
20: SOT (small outline transistor)
100: IC lead parts
C. [Camera Type]: Changes the image acquisition camera type (PENVICT)
which is specified in the production program’s part shape
data (ENVDT).
Setting examples:
0: Wide camera
1: Narrow camera
D. [Lighting]: Changes the part lighting type (PENVILIT) which is speci-
fied in the production program’s part shape data (VISION).
Setting examples:
0: Backlight
1: Frontlight
E. [Body]: Switches to the body data editing screen.
Close
Lead
ElementBody
Vision
Type
Camera
Type
Lighting
1
0
Sequence Number
FUJI
FUJI_CP7_2001
Vision Type Editor
Operator
Error
Push the START button.
Front
CCD Monitor GEM Servo Count
JOG:X Y CAM
Basic Data
Set Switch
123
10
CP7S2019E
A
B
C
D
HE F G
Machine System >> Editing Production Programs On the Machine
4-72
SYS-CP842-1.0E
F. [Element]: Switches to the element data editing screen.
G. [Lead]: Switches to the lead data editing screen.
H. [Close]: Returns to the production program editing screen.
Editing Operations
The following editing operations can be performed at this screen.
Problem Editing Operation
A vision processing error occurs during test
placement.
Error code: 0x1CA18005
No part line was found.
Error code: 0x1CA18006
No part line was found.
If the vision type is incorrect, edit the vision
type setting.
A vision processing error occurs during test
placement.
If the lighting is incorrect, edit the lighting
setting.
A vision processing error occurs during test
placement.
Error code: 0x1CB01101
Incorrect camera type setting.
If the camera type is incorrect, edit the
camera type setting.
T007E
Machine System >> Editing Production Programs On the Machine
SYS-CP842-1.0E 4-73
Element Data Editing Screen
Element data can be edited from this screen. For element data details, refer to the
SMD3 Operation Manual.
Screen Button Explanations
A. [Sequence No.]: Switches to the sequence search screen.
B. []: Changes the element data item which is being edited. If ele-
ment number 1 is being edited, the item is disabled (grayed
out) when this button is clicked.
C. []: Changes the element data item which is being edited. If final
element number is being edited, the item is disabled (grayed
out) when this button is clicked.
D. [Length]: Changes the lead element length (PGDELL) which is speci-
fied in the production program’s part shape data (ELDT).
E. [Width]: Changes the lead element width (PGDELW) which is speci-
fied in the production program’s part shape data (ELDT).
F. [Pitch]: Changes the lead element pitch (PGDELP) which is specified
in the production program’s part shape data (ELDT).
G. [Number of Leads]: Changes the number of lead element leads (PGDELQ) which
is specified in the production program’s part shape data
(ELDT).
H. [Side No.]: Changes the lead element position (direction) (PGDELSN)
which is specified in the production program’s part shape
data (ELDT).
Push the START button.
FUJI
Error
Operator
JOG:X Y CAM
Servo Count
GEMCCD Monitor
Element Data Editor
FUJI_CP7_2001
Front
Close
-0.6200
Position
X
Y
0.0000
[mm]
[mm]
0.1000
Lead Tolerance Values
Length
Width
0.1000
[mm]
[mm]
0.1000
Deviation
[mm]
Lead Data
Side
Number
0
P Pattern
3
Result 1
Pitch
0.0000
Width
0.3000
[mm]
0.5000
Length
[mm]
Count
1
[mm]
Lead
Body
Vision
Type
123
Sequence Number
1
Element
Set Switch
CP7S2020E
A
D
E
F
G
H
I
J
SRQP
B C
K
L
M
N
O
