Commands >> Command Descriptions
SYS-CP842-1.0E 5-43
Mid-stopper Up Loader Maintenance
Command Path: [Panel Loader] - [Loader Maintenance] - [Mid-stopper Up]
Press to raise the mid-stopper at the selected side of the machine. Press the START
button to execute after confirming that panels are not positioned above the stopper.
Revision history:
Move to Loading Position Panel Loader
Command Path: [Panel Loader] - [Move to Loading Position]
Press to move the main conveyor to the panel loading position.
Press the START button to execute the operation.
Revision history:
Move to Unloading Position Panel Loader
Command Path: [Panel Loader] - [Move to Unloading Position]
Press to move the main conveyor to the panel unloading position.
Press the START button to execute the operation.
Revision history:
Narrow Camera Nozzle Check
Command Path: [Nozzle Check] - [Narrow Camera]
Press to display the results for the narrow camera.
Revision history:
Network System
Command Path: [Maintenance] - [System] - [Network]
Press to access the screen at which network related settings can be made.
Revision history:
Commands >> Command Descriptions
5-44
SYS-CP842-1.0E
None Basic Configuration
Command Path: [Maintenance] - [Configuration] - [Basic] - [None]
Press to disable the use of forced device checks.
Revision history:
Nozzle Allocation Main
Command Path: [Nozzle Allocation]
Press to display the screen at which nozzle allocations can be displayed and changed.
Revision history:
Nozzle Bend Nozzle Check
Command Path: [Nozzle Check] - [Nozzle Bend]
Press to select nozzle bend as an item for nozzle measurement.
Revision history:
Nozzle Check Main
Command Path: [Nozzle Check]
Press to access the screen at which nozzle check inspection items can be made.
Revision history:
Nozzle Check Conditions Machine Configuration Data
Command Path: [Maintenance] - [Configuration] - [Nozzle Check Conditions]
Press to access the screen at which nozzles inspection conditions can be selected.
Revision history:
Nozzle Check Details Nozzle Check
Command Path: [Nozzle Check] - [Nozzle Check Details]
Press to access the screen at which the results of nozzle inspection can be viewed.
Revision history:
Commands >> Command Descriptions
SYS-CP842-1.0E 5-45
Nozzle Check Limits Nozzle Check
Command Path: [Nozzle Check] - [Nozzle Check Limits]
Press to access the screen at which nozzle check tolerance values can be set.
Revision history:
Nozzle Data Production
Command Path: [Production] - START button - [Nozzle Data]
Press to change the display during production to nozzle related information.
Revision history:
Nozzle Length Nozzle Check
Command Path: [Nozzle Check] - [Nozzle Length]
Press to select nozzle length as an item for nozzle measurement.
Revision history:
Nozzle Size Nozzle Check
Command Path: [Nozzle Check] - [Nozzle Size]
Press to select nozzle size as an item for nozzle measurement.
Revision history:
Nozzle Size Statistical Nozzle Skip
Command Path: [Maintenance] - [Configuration] - [Statistical Nozzle Skip] - [Nozzle
Size]
Press to select the nozzle size as an inspection item for nozzles which are skipped by
means of nozzle statistical processing.
Revision history:
Nozzle Skip Main
Command Path: [Nozzle Skip]
Press to access the screen at which nozzle skip settings can be made.
Revision history:
