Commands >> Command Descriptions
SYS-CP842-1.0E 5-29
Carrier Retract Loader Maintenance
Command Path: [Panel Loader] - [Loader Maintenance] - [Carrier Retract]
Press to retract the carrier at the selected side of the machine. Press the START but-
ton to execute.
Revision history:
Carrier Unclamp Loader Maintenance
Command Path: [Panel Loader] - [Loader Maintenance] - [Carrier Unclamp]
Press to unclamp the carrier at the selected side of the machine. Press the START
button to execute.
Revision history:
Change Recovery
Command Path: [Recovery] - [Change]
Press to change the number of times the machine will attempt a recovery.
Selecting this command displays the Numeric Keypad. Input a value and press [OK].
Revision history:
Change Name Operator Settings
Command Path: [Maintenance] - [Operator] - [Change Name]
Press to access the screen at which operator names can be changed.
Revision history:
Changeover Operation
Command Path: [Operation] - [Changeover]
Press to set the device table mode to Changeover.
Revision history:
Commands >> Command Descriptions
5-30
SYS-CP842-1.0E
Changeover Checks Machine Configuration Data
Command Path: [Maintenance] - [Configuration] - [Changeover Checks]
Press to access the screen at which settings can be made to automatically activate
functions after changeover.
Revision history:
Change Pallet Main
Command Path: [Change Pallet]
Press to access the screen at which pallet change commands and instructions can be
accessed.
Revision history:
Chg Scheduled Panels Program
Command Path: [Program] - [Chg Scheduled Panels]
Press to change the number of scheduled panels for the selected program.
Selecting this command displays the Numeric Keypad. Input a value and press [OK].
Revision history:
Clamp Panel Loader
Command Path: [Panel Loader] - [Clamp]
Press to clamp the panel that has been loaded onto the main conveyor.
Press the START button to execute the operation.
Revision history:
Clear Completed Panels Program
Command Path: [Program] - [Clear Completed Panels]
Press to set the Completed Panels item for the selected program to 0.
Revision history:
Commands >> Command Descriptions
SYS-CP842-1.0E 5-31
Coarse Pos Trace Settings
Command path: [Maintenance] - [Vision System] - [Image Buffer] - [Trace Settings] -
[Coarse Pos]
Press to display trace data with coarse positioning information.
Revision history:
Configuration Maintenance
Command Path: [Maintenance] - [Configuration]
Press to access the screen at which the commands related to machine configuration
settings can be selected.
Revision history:
Connection Port Number Handy Terminal
Command Path: [Maintenance] - [Configuration] - [Handy Terminal] - [Connection
Port Number]
Press to display the numeric keypad at which the Handy Terminal connection port
number can be specified.
Revision history:
Continued Recovery
Command Path: [Recovery] - [Continued]
Press to set the recovery action to Continued.
Revision history:
Conveyor Main
Command Path: [Conveyor]
Press to display the screen at which the conveyor width or mid-stopper position can be
changed.
Revision history:
