Commands >> Command Descriptions
5-40
SYS-CP842-1.0E
Load Operator Data Manager
Command Path: [Maintenance] - [Operator] - [Data Manager] - [Load]
Press to display the screen at which operator settings can be copied from the hard disk
or floppy disk.
Revision history:
Loader Machine Configuration Data
Command Path: [Maintenance] - [Configuration] - [Loader]
Press to access the screen at which the panel flow direction and use of the panel
request signal can be specified.
Revision history:
Loader Cylinder Maintenance
Command Path: [Maintenance] - [Loader Cylinder]
Press to access the screen at which loader related adjustment items can be selected.
Revision history:
Loader Data Production
Command Path: [Production] - START button - [Loader Data]
Press to change the display during production to loader related information.
Revision history:
Loader Maintenance Panel Loader
Command Path: [Panel Loader] - [Loader Maintenance]
Press to access the screen at which loader maintenance and panel conveyance com-
mands can be accessed.
Revision history:
Commands >> Command Descriptions
SYS-CP842-1.0E 5-41
Loading Pos Machine Calibration Data
Command Path: [Maintenance] - [Calibration] - [Loading Pos]
Press to access the screen at which the panel loading positions can be set in calibra-
tion data.
Revision history:
Load Panel Panel Loader
Command Path: [Panel Loader] - [Load Panel]
Press to unload the panel currently on the main conveyor, and load a new panel to the
main conveyor.
Press the START button to execute the operation.
Revision history:
Load Two Panels Panel Loader
Command Path: [Panel Loader] - [Load Two Panel]
Press to unload the panel currently on the main conveyor, and load two new panels to
the main conveyor.
Press the START button to execute the operation.
Revision history:
Machine Recovery
Command Path: [Recovery] - [Machine]
Press to use the recovery limit setting at the machine.
Revision history:
Machine Configuration System Backup
Command Path: [Maintenance] - [Data Manager] - [System Backup] - [Machine Con-
figuration]
Press to select machine configuration data for backup.
Revision history:
Commands >> Command Descriptions
5-42
SYS-CP842-1.0E
Main Conveyor Pick-up Loader Maintenance
Command Path: [Panel Loader] - [Loader Maintenance] - [Main Conveyor Pick-up]
Press to load the panel on the in-carrier to the main conveyor. Press the START but-
ton to execute.
Revision history:
Maintenance Main
Command Path: [Maintenance]
Press to access the screen at which maintenance related commands can be selected.
Revision history:
Mark Camera Resolution Machine Calibration Data
Command Path: [Maintenance] - [Calibration] - [Mark Camera Resolution]
Press to access the screen at which the mark camera resolution can be measured.
Revision history:
Mark Editor Production
Command Path: [Production] - [Mark Editor]
Press to access the screen at which fiducial marks can be edited.
Revision history:
Mid-stopper Down Loader Maintenance
Command Path: [Panel Loader] - [Loader Maintenance] - [Mid-stopper Down]
Press to lower the mid-stopper at the selected side of the machine. Press the START
button to execute.
Revision history:
Mid-stopper Pos. Conveyor Width
Command Path: [Conveyor] - [Mid-stopper Pos.]
Press to display the screen at which the mid-stopper position can be specified.
Revision history:
