Commands >> Command Descriptions
SYS-CP842-1.0E 5-51
Production Operation
Command Path: [Operation] - [Production]
Press to set the operation mode to Production.
Revision history:
Program Main
Command Path: [Program]
Press to access the screen at which program related settings can be made.
Revision history:
Program Backup Data Manager
Command Path: [Maintenance] - [Data Manager] - [Program Backup]
Press to access the screen at which programs can be backed up.
Revision history:
Program Coordinates Position
Command Path: [Position] - [Program Coordinates]
Press to display the numeric keypad for specification of the coordinates to which the
selected axis (selected at the commands [X-axis] and [Y-axis]) will be moved.
Revision history:
Program Editor Maintenance
Command Path: [Maintenance] - [Program Editor]
Press to access the screen at which program related settings can be made.
Revision history:
Read Operation
Command Path: [Operation] - [Read]
Press to enable the detection of skip marks.
Revision history:
Commands >> Command Descriptions
5-52
SYS-CP842-1.0E
Recovery Main
Command Path: [Recovery]
Press to access the screen at which recovery related settings can be made.
Revision history:
Reinspect Image Buffer
Command Path: [Maintenance] - [Vision System] - [Image Buffer] - [Reinspect]
Press to reinspect the image that is stored in the image buffer.
Revision history:
Remaining Panels Board Skip
Command Path: [Board Skip Data] - [Remaining Panels]
Press to enable board skip settings for all remaining panels.
Revision history:
Restore Program Data Manager
Command Path: [Maintenance] - [Data Manager] - [Restore Program]
Press to display the screen at which programs can be restored.
Revision history:
Restore System Data Manager
Command Path: [Maintenance] - [Data Manager] - [Restore System]
Press to display the screen at which the system settings can be restored.
Revision history:
Results Trace Settings
Command Path: [Maintenance] - [Vision System] - [Image Buffer] - [Trace Settings] -
[Results]
Press for a graphical display of the inspection results.
Revision history:
Commands >> Command Descriptions
SYS-CP842-1.0E 5-53
Right to Left Loader
Command Path: [Maintenance] - [Configuration] - [Loader] - [Right to Left]
Press to select panel conveyance from right to left.
Revision history:
Save Operator Data Manager
Command Path: [Maintenance] - [Operator] - [Data Manager] - [Save]
Press to display the screen at which operator settings can be output.
Revision history:
Servo I/O Check
Command Path: [Maintenance] - [I/O check] - [Servo]
Press to access the screen at which servo related I/O checks can be performed.
Revision history:
Servo Coordinates Position
Command Path: [Position] - [Servo Coordinates]
Press to display the numeric keypad for specification of the coordinates to which the
selected axis (selected at the commands [X-axis] and [Y-axis]) will be moved.
Revision history:
Servo Count Command bar (All Screens)
Command Path: [Servo Count]
Press to display a dialog box where the servo counts for all axis can be viewed in
pulses or mm/degree.
Revision history:
Servo Setup Maintenance
Command Path: [Maintenance] - [Servo Setup]
Press to display the screen at which the servos can be checked.
Revision history:
