Commands >> Command Hierarchy 5-18 SYS-CP842-1.0E Maintenance Configuration (Continued) C73SC008E-8 Machine Configuration Data (Continued) Machine Function Settings (Continued) Machine Function Settings (Continued)…
Commands >> Command Hierarchy
SYS-CP842-1.0E 5-17
Maintenance
Configuration
(Continued)
C73SC008E-7
Machine Configuration
Data(Continued)
Machine Function
Settings
(Continued)
Machine Function Settings
(Continued)
Barcode Management
Parts Reject
Confirmation
Parts Reject Confirmation
Yes
No
Close
Use part reject confirmation?
Barcode Management
Use Upper ID Reader
Use Lower ID Reader
Upper ID Reader Port → Numeric Keypad
Lower ID Reader Port → Numeric Keypad
Change Test Reader
Change Test Mode
Start
Close
Panel ID Reader Settings
Panel ID Read Test
Parts Administration System
Use Handy Terminal
Use Setup Sensor and LED system
Use Fujitrax-Verifier
Use Fujitrax-Profile
Use
Not use
H → Numeric Keypad
M → Numeric Keypad
S → Numeric Keypad
Edit
→ Numeric Keypad
Remaining parts administration
Simple Parts Mgmt. Settings
Parts count settings
Handy Terminal Port Number → Numeric Keypad
Handy Terminal Settings
Handy Terminal Type
Allow Manual
Enable Automatic Position Selecting
Select the appropriate Verification system equipment.
Parts Administration
System
? (Help Button)
→
DID Joint Symbol
Use
Set → Virtual Keyboard
Production
Operation Mode
: Command name
: Screen name
Production
: Command group
: Continued on the next page
: Press to scroll upwards
Legend
: Press to scroll downwards
( )
: General description
[ ]
: Push button
→
: Displays separate dialog box
Commands >> Command Hierarchy
5-18
SYS-CP842-1.0E
Maintenance
Configuration
(Continued)
C73SC008E-8
Machine Configuration
Data
(Continued)
Machine Function
Settings
(Continued)
Machine Function
Settings
(Continued)
Parts Administration System
(Continued)
Parts Administration
System
(Continued)
H → Numeric Keypad
M → Numeric Keypad
S → Numeric Keypad
Parts out worning time
Communication Timeout Period → Numeric Keypad
Use Fujitrax Verifier
Use Fujitrax Verifier
Stage1 → Numeric Keypad
Stage2
→ Numeric Keypad
Miss prevention timer → Numeric Keypad
Feeder loading timer → Numeric Keypad
Setup Sensor and LED system connection port number
Use Setup Sensor and LED system
Close
Feeder ID reading system setting
Port Number → Numeric Keypad
Use Device Status Flag
Use Feeder Type Check Function
Read ID of Error Devices Only
Feeder ID reading system setting
Edit(Host name) → Virtual Keyboard
Edit(IP address) → Virtual Keyboard
Default Settings
Database settings
Use Fujitrax Profiler
Question
OK
Cancel
Reduced Vibration
Mode
Reduced Vibration Mode
Standard
Reduced Vibration
Standard
Reduced Vibration
Close
Close
D-Axis
XY-Axis
Statictical Nozzle Skip
Statistical Nozzle Skip
Set → Numeric Keypad
Enabled
Disabled
Error Limit
Holder1-6 → Numeric Keypad
Stop Conditions
Statistical Skip
Production
Operation Mode
: Command name
: Screen name
Production
: Command group
: Continued on the next page
: Press to scroll upwards
Legend
: Press to scroll downwards
( )
: General description
[ ]
: Push button
→
: Displays separate dialog box
Commands >> Command Hierarchy
SYS-CP842-1.0E 5-19
Maintenance
Configuration
(Continued)
C73SC008E-9
Machine Configuration
Data
(Continued)
Machine Function
Settings
(Continued)
Machine Function
Settings
(Continued)
Nozzle Skip Conditions
Changeover Check
Auto Display
Parts Height
Vision Monitor
Condition of Nozzle Check Skip
Changeover Checks
Enabled
Enabled
Disabled
Close
Compulsory Mid-stopper Check
Disabled
Compulsory Nozzle Check
Parts Height Detection
Used
Used
Not used
Close
Auto Recovery
Not used
Machine
Recovery Reference
Part Data
Change → Numeric Keypad
Recovery Limit
Part Height Detection Sensor
Automatic Operation Display
Sequence Progress Status
Yes
No
Close
Select up to two items for display.
Cam Speed Display
Display nozzle and device information screen during production?
Nozzle Check Conditions
Nozzle Size
Close
Nozzle Length
Nozzle Bend
Errors
Nozzle Center
Vision Monitor Configuration Method
Vision Monitor
No Use
Close
4 Divisions
All
16 Divisions
9 Divisions
Production
Operation Mode
: Command name
: Screen name
Production
: Command group
: Continued on the next page
: Press to scroll upwards
Legend
: Press to scroll downwards
( )
: General description
[ ]
: Push button
→
: Displays separate dialog box
