Machine System >> Editing Production Programs On the Machine
4-76
SYS-CP842-1.0E
Editing Operations
The following editing operations can be performed at this screen.
Problem Editing Operation
A vision processing error occurs during test
placement.
Error code: 0x1CAA000C
Body edge could not be detected.
If the lead data is incorrect, edit the detection
position item.
A vision processing error occurs during test
placement.
Error code: 0x1CAA0010
Rough positioning cannot be performed.
If the lead data is incorrect (image brightness
is unsuitable), edit the "luminosity" item.
A vision processing error occurs during test
placement.
Error code: 0x1CAA000D
Part size differs (excessively) from the size
specified in part data.
If the lead data is incorrect, edit the pitch
deviation tolerance item.
T009E
Machine System >> Administrative Functions
SYS-CP842-1.0E 4-77
4.3 Administrative Functions
4.3.1 Displaying the Software Versions
Users can access the following dialog box by pressing the [FUJI] button in the top left
of the touch panel. Press [Close] to clear the version display.
Machine System >> Administrative Functions
4-78
SYS-CP842-1.0E
4.3.2 Setting Up a New User
The machine system can control what functions are used by operators by means of its
built-tin security settings. An account can be created for each person who uses the
machine.
Procedure
1 Press [Maintenance] - [Operator] from the [Main] screen. The [Operator Set-
tings] screen displays.
2 Press [Copy] to display the [Copy Operator Settings] screen. Select a user name
with settings similar to those that will be specified for the user to be added.
3 Next press [Add], then [Yes] at the confirmation message which displays.
4 Enter the user name, and password at the keyboard. The password must be
entered twice for confirmation.
5 The [Language Manager] screen displays when these entries are complete.
Press [Close] to complete the users settings.
The name added appears in the user list when the machine starts up. The new user
has the same access to commands as the user whose user settings were copied. Refer
to the following section for details of how to customize the settings for a user name.
