Commands >> Command Descriptions
SYS-CP842-1.0E 5-45
Nozzle Check Limits Nozzle Check
Command Path: [Nozzle Check] - [Nozzle Check Limits]
Press to access the screen at which nozzle check tolerance values can be set.
Revision history:
Nozzle Data Production
Command Path: [Production] - START button - [Nozzle Data]
Press to change the display during production to nozzle related information.
Revision history:
Nozzle Length Nozzle Check
Command Path: [Nozzle Check] - [Nozzle Length]
Press to select nozzle length as an item for nozzle measurement.
Revision history:
Nozzle Size Nozzle Check
Command Path: [Nozzle Check] - [Nozzle Size]
Press to select nozzle size as an item for nozzle measurement.
Revision history:
Nozzle Size Statistical Nozzle Skip
Command Path: [Maintenance] - [Configuration] - [Statistical Nozzle Skip] - [Nozzle
Size]
Press to select the nozzle size as an inspection item for nozzles which are skipped by
means of nozzle statistical processing.
Revision history:
Nozzle Skip Main
Command Path: [Nozzle Skip]
Press to access the screen at which nozzle skip settings can be made.
Revision history:
Commands >> Command Descriptions
5-46
SYS-CP842-1.0E
Nozzle Skip Conditions Machine Configuration Data
Command Path: [Maintenance] - [Configuration] - [Nozzle Skip Conditions]
Press to access the screen at which the conditions for nozzle skips can be selected and
cleared.
Revision history:
Operation Main
Command Path: [Operation]
Press to access the screen at which operation mode settings are made.
Revision history:
Operator Maintenance
Command Path: [Maintenance] - [Operator]
Press to access the screen at which the display languages can be selected and other
operator settings can be copied, deleted and loaded or saved from or to the hard disk or
floppy disk.
Revision history:
Options Maintenance
Command Path: [Maintenance] - [Options]
Press to access the screen at which options (Status Reset, Warranty) can be selected.
Revision history:
Origin Pos Offset Machine Calibration Data
Command Path: [Maintenance] - [Calibration] - [Origin Pos Offset]
Press to access the screen at which the axes origin positions can be set in calibration
data.
Revision history:
Commands >> Command Descriptions
SYS-CP842-1.0E 5-47
Out-carrier Pick-up Loader Maintenance
Command Path: [Panel Loader] - [Loader Maintenance] - [Out-carrier Pick-up]
Press to unload the panel on the main conveyor to the out-carrier. Press the START button
to execute.
Revision history:
Out-lifter Pick-up Loader Maintenance
Command Path: [Panel Loader] - [Loader Maintenance] - [Out-lifter Pick-up]
Press to unload the panel on the out-carrier to the out-lifter. Press the START button
to execute.
Revision history:
Output Signal ON/OFF I/O Check
Command Path: [Maintenance] - [I/O check] - [Standard]/[Servo] - [Output signal
ON/OFF]
Press to turn the selected output signal on or off.
Use the arrow-buttons to scroll up and down through the list of input and output sig-
nals.
Revision history:
Out-side Loader Maintenance
Command Path: [Panel Loader] - [Loader Maintenance] - [Out-side]
Press to select the panel unloading side of the machine as the target for subsequent
loader commands.
Revision history:
Pallet Change Pos Machine Calibration Data
Command Path: [Maintenance] - [Calibration] - [Pallet Change Pos]
Press to access the screen at which the pallet change position can be set in calibration
data.
Revision history:
