I/O Map >> Standard Input and Output Signals

6-10

SYS-CP842-1.0E

6.1.2 Standard Output Signals

Output-1

Address Signal Name Description

Y000 START SWITCH LAMP ON1 Side1 Start switch lamp on

Y001 READY ON1 LAMP ON Side1 Ready on lamp on

Y002 BUZZER ON1 Side1 Buzzer on

Y003 Not used

Y004 SIGNAL TOWER RED ON Signal tower (red lamp)

Y005 SIGNAL TOWER YELLOW ON Signal tower (yellow lamp)

Y006 SIGNAL TOWER BLUE ON Signal tower (blue lamp)

Y007 SIGNAL TOWER RED BLINK Signal tower (red flash)

Y008 SIGNAL TOWER YELLOW BLINK Signal tower (yellow flash)

Y009 SIGNAL TOWER BLUE BLINK Signal tower (blue flash)

Y00A START SWITCH LAMP ON2 Side2 Start switch lamp on

Y00B READY ON2 LAMP ON Side2 Ready on lamp on

Y00C BUZZER ON2 Side2 Buzzer on

Y00D Side2 ENABLE Side 2 Enable

Y00E CAM AXIS ABS SETUP Cam-axis ABS setup

Y00F TIME COUNTER ON Time counter on

Y010 MASTER ON Master on

Y011 OVERTRAVEL CUT Cut overtravel control

Y012 FRONT DOOR LOCK Front door lock

Y013 REAR DOOR D1 LOCK Rear door D1 lock

Y014 REAR DOOR MIDDLE LOCK Rear door middle lock

Y015 REAR DOOR D2 LOCK Rear door D2 lock

Y016 SHUTDOWN Shutdown

Y017 FIDUCIAL LAMP ON Fiducial lamp on

Y018 PANEL REQUEST Panel request signal from previous stage

Y019 BOARD AVAILABLE Panel available signal to next stage

Y01A FOLLOW PERMIT OUTPUT Permit follow up (HELPS)

Y01B X AXIS ABS SETUP X-axis ABS setup

Y01C Y AXIS ABS SETUP Y-axis ABS setup

Y01D Z AXIS ABS SETUP Z-axis ABS setup

Y01E PQ AXIS ABS SETUP PQ-axis ABS setup

Y01F FQ AXIS ABS SETUP FQ-axis ABS setup

Y020 FRONTLIGHT 1 ON Frontlight 1 on

Y021 FRONTLIGHT 2 ON Frontlight 2 on

I/O Map >> Standard Input and Output Signals

SYS-CP842-1.0E 6-11

Y022 VACUUM BACKUP Vacuum backup

Y023 MAIN-LIFTER MIDDLE OT INVALID Main-lifter middle overtravel invalid

Y024 Not used

Y025 Not used

Y026 VACUUM PUMP ON Vacuum pump on

Y027 RING BLOW ON Ring blow on

Y028 OIL COOLER ON Oil cooler on

Y029 IN-CONVEYOR MOTOR ON In-conveyor motor on

Y02A IN-CONVEYOR MOTOR REVERSE ON In-conveyor motor reverse on

Y02B IN-CONVEYOR MOTOR REDUCE ON In-conveyor motor reduce speed

Y02C Not used

Y02D OUT-CONVEYOR MOTOR ON Out-conveyor motor on

Y02E CONVEYOR WIDTH MOTOR ON Conveyor width motor on (HELPS)

Y02F CONVEYOR WIDTH MOTOR REVERSE ON Conveyor width reverse motor on (HELPS)

Y030 ST1 PICKUP SOL DISENGAGED Stn1 Pickup Solenoid off

Y031 ST1 PICKUP SOL ENGAGED Stn1 Pickup Solenoid on

Y032 ST1 TAPE FEED SOL DISENGAGED Stn1 tape feed solenoid off

Y033 ST1 TAPE FEED SOL ENGAGED Stn1 tape feed solenoid on

Y034 ST9 PLACE SOL DISENGAGED Stn9 placing solenoid off

Y035 ST9 PLACE SOL ENGAGED Stn9 placing solenoid on

Y036 ST14 NOZZLE CHANGE SOL DISENGAGED Stn14 nozzle switch solenoid off

Y037 ST14 NOZZLE CHANGE SOL ENGAGED Stn14 nozzle switch solenoid on

Y038 Not used

Y039 Not used

Y03A ST9 (ST13) AIR BLOW ON Stn9 (Stn13) Air blow on

Y03B Not used

Y03C Not used

Y03D SIDE 2 LOCK LAMP ON Side2 Fix operation lamp on

Y03E N FEED TIMES TAPE CUT CYLINDER Number of tape cut operations (n)

Y03F SEQUENCE DATA RECEIVED REPORT

(D1)

Sequence data received report (D1)

Y040 N FEED TIMES FEEDER CYLINDER Number of tape feed operations (n)

Y041 Not used

Y042 FOREIGN MATTER DETECT ORDER Foreign matter presence inspection

Y043 XY-TABLE PANEL CLAMP (FIXED RAIL) XY-table panel clamp (fixed rail)

Y044 XY-TABLE PANEL UNCLAMP (FIXED RAIL) XY-table panel unclamp (fixed rail)

Y045 XY-TABLE PANEL CLAMP (ADJUSTABLE

RAIL)

XY-table panel clamp (adjustable rail)

Address Signal Name Description

I/O Map >> Standard Input and Output Signals

6-12

SYS-CP842-1.0E

Y046 XY-TABLE PANEL UNCLAMP

(ADJUSTABLE RAIL)

XY-table panel unclamp (adjustable rail)

Y047 MCID CONVEYOR MOTOR ON MCID conveyor motor on

Y048 MCID CONVEYOR MOTOR REDUCE ON MCID conveyor motor speed reduce

Y049 MCID CONVEYOR MOTOR REVERSE ON MCID conveyor motor reverse on

Y04A MCID CONVEYOR WIDTH MOTOR ON MCID conveyor width motor on

Y04B MCID CONVEYOR WIDTH MOTOR

REVERSE ON

MCID conveyor width motor reverse on

Y04C MCID RAISE IN-CONVEYOR STOPPER MCID in-conveyor stopper up

Y04D MCID RAISE IN-REVERSE CONVEYOR

STOPPER

MCID in-reverse conveyor stopper up

Y04E BC LAMP 1 Barcode reader lamp 1

Y04F BC LAMP 2 Barcode reader lamp 2

Address Signal Name Description
