I/O Map >> Standard Input and Output Signals 6-12 SYS-CP842-1.0E Y046 XY-TABLE PANEL UNCLAMP (ADJUSTABLE RAIL) XY-table panel u nclamp (adjustable rail) Y047 MCID CONVEYOR MOTOR ON MCID conveyor motor on Y048 MCID …

I/O Map >> Standard Input and Output Signals

SYS-CP842-1.0E 6-11

Y022 VACUUM BACKUP Vacuum backup

Y023 MAIN-LIFTER MIDDLE OT INVALID Main-lifter middle overtravel invalid

Y024 Not used

Y025 Not used

Y026 VACUUM PUMP ON Vacuum pump on

Y027 RING BLOW ON Ring blow on

Y028 OIL COOLER ON Oil cooler on

Y029 IN-CONVEYOR MOTOR ON In-conveyor motor on

Y02A IN-CONVEYOR MOTOR REVERSE ON In-conveyor motor reverse on

Y02B IN-CONVEYOR MOTOR REDUCE ON In-conveyor motor reduce speed

Y02C Not used

Y02D OUT-CONVEYOR MOTOR ON Out-conveyor motor on

Y02E CONVEYOR WIDTH MOTOR ON Conveyor width motor on (HELPS)

Y02F CONVEYOR WIDTH MOTOR REVERSE ON Conveyor width reverse motor on (HELPS)

Y030 ST1 PICKUP SOL DISENGAGED Stn1 Pickup Solenoid off

Y031 ST1 PICKUP SOL ENGAGED Stn1 Pickup Solenoid on

Y032 ST1 TAPE FEED SOL DISENGAGED Stn1 tape feed solenoid off

Y033 ST1 TAPE FEED SOL ENGAGED Stn1 tape feed solenoid on

Y034 ST9 PLACE SOL DISENGAGED Stn9 placing solenoid off

Y035 ST9 PLACE SOL ENGAGED Stn9 placing solenoid on

Y036 ST14 NOZZLE CHANGE SOL DISENGAGED Stn14 nozzle switch solenoid off

Y037 ST14 NOZZLE CHANGE SOL ENGAGED Stn14 nozzle switch solenoid on

Y038 Not used

Y039 Not used

Y03A ST9 (ST13) AIR BLOW ON Stn9 (Stn13) Air blow on

Y03B Not used

Y03C Not used

Y03D SIDE 2 LOCK LAMP ON Side2 Fix operation lamp on

Y03E N FEED TIMES TAPE CUT CYLINDER Number of tape cut operations (n)

Y03F SEQUENCE DATA RECEIVED REPORT

(D1)

Sequence data received report (D1)

Y040 N FEED TIMES FEEDER CYLINDER Number of tape feed operations (n)

Y041 Not used

Y042 FOREIGN MATTER DETECT ORDER Foreign matter presence inspection

Y043 XY-TABLE PANEL CLAMP (FIXED RAIL) XY-table panel clamp (fixed rail)

Y044 XY-TABLE PANEL UNCLAMP (FIXED RAIL) XY-table panel unclamp (fixed rail)

Y045 XY-TABLE PANEL CLAMP (ADJUSTABLE

RAIL)

XY-table panel clamp (adjustable rail)

Address Signal Name Description

I/O Map >> Standard Input and Output Signals

6-12

SYS-CP842-1.0E

Y046 XY-TABLE PANEL UNCLAMP

(ADJUSTABLE RAIL)

XY-table panel unclamp (adjustable rail)

Y047 MCID CONVEYOR MOTOR ON MCID conveyor motor on

Y048 MCID CONVEYOR MOTOR REDUCE ON MCID conveyor motor speed reduce

Y049 MCID CONVEYOR MOTOR REVERSE ON MCID conveyor motor reverse on

Y04A MCID CONVEYOR WIDTH MOTOR ON MCID conveyor width motor on

Y04B MCID CONVEYOR WIDTH MOTOR

REVERSE ON

MCID conveyor width motor reverse on

Y04C MCID RAISE IN-CONVEYOR STOPPER MCID in-conveyor stopper up

Y04D MCID RAISE IN-REVERSE CONVEYOR

STOPPER

MCID in-reverse conveyor stopper up

Y04E BC LAMP 1 Barcode reader lamp 1

Y04F BC LAMP 2 Barcode reader lamp 2

Address Signal Name Description

I/O Map >> Standard Input and Output Signals

SYS-CP842-1.0E 6-13

Ouput-2

Address Signal Name Description

Y050 SIGNAL TOWER YELLOW ON 1 Signal tower (Yellow lamp 1)

Y051 SIGNAL TOWER YELLOW BLINK 1 Signal tower (Yellow blink 1)

Y052 D1 PCU CLAMP (1) D1 Pallet change unit clamp 1

Y053 D1 PCU UNCLAMP (1) D1 Pallet change unit unclamp 1

Y054 D1 PCU CLAMP (2) D1 Pallet change unit clamp 2

Y055 D1 PCU UNCLAMP (2) D1 Pallet change unit unclamp 2

Y056 D1 PALLET UP Raise D1 pallet

Y057 D1 PALLET DOWN Lower D1 pallet

Y058 D1 TABLE STOPPER CLAMP D1 table stopper clamp

Y059 D1 TABLE STOPPER UNCLAMP D1 table stopper unclamp

Y05A Not used

Y05B Not used

Y05C Not used

Y05D Not used

Y05E ACQ.FEEDER ID Acquire feeder ID

Y05F SIDE1 LOCK LAMP ON Side 1 Fix operation lamp on

Y060 SIGNAL TOWER YELLOW ON 2 Signal tower (Yellow lamp 2)

Y061 SIGNAL TOWER YELLOW BLINK 2 Signal tower (Yellow blink 2)

Y062 D2 PCU CLAMP (1) D2 Pallet change unit clamp 1

Y063 D2 PCU UNCLAMP (1) D2 Pallet change unit unclamp 1

Y064 D2 PCU CLAMP (2) D2 Pallet change unit clamp 2

Y065 D2 PCU UNCLAMP (2) D2 Pallet change unit unclamp 2

Y066 D2 PALLET UP Raise D2 pallet

Y067 D2 PALLET DOWN Lower D2 pallet

Y068 D2 TABLE STOPPER CLAMP D2 table stopper clamp

Y069 D2 TABLE STOPPER UNCLAMP D2 table stopper unclamp

Y06A Not used

Y06B Not used

Y06C Not used

Y06D Not used

Y06E Not used

Y06F SEQUENCE DATA RECEIVED REPORT

(D2)

Sequencer data received report (D2)

Y070 RAISE IN-CONVEYOR 2ND PANEL

STOPPER

Raise in-conveyor 2nd panel stopper

Y071 LOWER IN-CONVEYOR 2ND PANEL

STOPPER

Lower in-conveyor 2nd panel stopper
