Commands >> Command Descriptions
5-56
SYS-CP842-1.0E
Tolerance Trace Settings
Command Path: [Maintenance] - [Vision System] - [Image Buffer] - [Trace Settings] -
[Tolerance]
Press for a graphical display of the tolerance information.
Revision history:
Trace Settings Image Buffer
Command Path: [Maintenance] - [Vision System] - [Image Buffer] - [Trace Settings]
Press to access the screen at which trace-related settings can be specified.
Revision history:
Travel Limits Machine Calibration Data
Command Path: [Maintenance] - [Calibration] - [Travel Limits]
Press to access the screen at which machine axes maximum and minimum travel lim-
its can be set in calibration data.
Revision history:
Unclamp Panel Loader
Command Path: [Panel Loader] - [Unclamp]
Press to release the main conveyor panel clamp.
Press the START button to execute the operation.
Revision history:
Unload Panel Loader
Command Path: [Panel Loader] - [Unload]
Press to unload the panel(s) currently on the main conveyor.
Press the START button to execute the operation.
Revision history:
Commands >> Command Descriptions
SYS-CP842-1.0E 5-57
Vision Command bar (All Screens)
Command Path: [Vision]
Press to display a dialog box which allows for selection of the camera used to acquire
the image displayed at the machine monitor.
Revision history:
Vision Error Basic Configuration
Command Path: [Maintenance] - [Configuration] - [Basic] - [Vision Error]
Press to execute a forced device check when a parts out condition, a pickup error, or a
vision processing error occurs.
Revision history:
Vision Error Basic Configuration
Command Path: [Maintenance] - [Configuration] - [Basic] - [Vision Error]
Press to perform a changeover to the next device when a parts out condition, a pickup
error, or a vision processing error occurs.
Revision history:
Vision System Maintenance
Command Path: [Maintenance] - [Vision System]
Press to access the screen at which the vision system related commands can be
selected.
Revision history:
Warranty Options
Command Path: [Maintenance] - [Options] - [Warranty]
Press to access the screen at which machine and software warranty related informa-
tion displays.
Revision history:
Commands >> Command Descriptions
5-58
SYS-CP842-1.0E
Wide Camera Nozzle Check
Command Path: [Nozzle Check] - [Wide Camera]
Press to display the results for the wide camera.
Revision history:
X-axis Position
Command Path: [Position] - [X-axis]
Press to select the X-axis as the target axis for movement. Select [X-axis] and enter
the required coordinates at [Program Coordinates] or [Servo Coordinates].
Revision history:
Y-axis Position
Command Path: [Position] - [Y-axis]
Press to select the Y-axis as the target axis for movement. Select [Y-axis] and enter
the required coordinates at [Program Coordinates] or [Servo Coordinates].
Revision history:
