Commands >> Command Descriptions
SYS-CP842-1.0E 5-49
Parts Miss Basic Configuration
Command Path: [Maintenance] - [Configuration] - [Basic] - [Parts Miss]
Press to execute changeover to a next device after pick-up errors.
Revision history:
Parts/Nozzle Reference Machine Calibration Data
Command Path: [Maintenance] - [Calibration] - [Parts/Nozzle Reference]
Press to access the screen at which the parts pick-up height can be measured and set.
Revision history:
Parts Out Basic Configuration
Command Path: [Maintenance] - [Configuration] - [Basic] - [Parts Out]
Press to execute a forced device check when parts are exhausted.
Revision history:
Parts Out Basic Configuration
Command Path: [Maintenance] - [Configuration] - [Basic] - [Parts Out]
Press to execute changeover to a next device when parts are exhausted.
Revision history:
Pass Operation
Command Path: [Operation] - [Pass]
Press to set the operation mode to Pass.
Revision history:
Pick-up Miss Basic Configuration
Command Path: [Maintenance] - [Configuration] - [Basic] - [Pick-up Miss]
Press to perform a forced device check when a parts out condition or pickup error
occurs.
Revision history:
Commands >> Command Descriptions
5-50
SYS-CP842-1.0E
Pick-up Miss Basic Configuration
Command Path: [Maintenance] - [Configuration] - [Basic] - [Pick-up Miss]
Press to perform a changeover to the next device when a parts out condition or a
pickup error occurs.
Revision history:
Pick-up pos Machine Calibration Data
Command Path: [Maintenance] - [Calibration] - [Pick-up Pos]
Press to access the screen at which the pick-up reference positions can be set.
Revision history:
Pick-up Reference Machine Calibration Data
Command Path: [Maintenance] - [Calibration] - [Pick-up Reference]
Press to access the Pickup Reference Position Setting screen.
Revision history:
Place Reference Machine Calibration Data
Command Path: [Maintenance] - [Calibration] - [Place Reference]
Press to access the screen at which the placing position can be set in calibration data.
Revision history:
Position Main
Command Path: [Position]
Press to access the screen at which positioning commands can be selected.
Revision history:
Production Main
Command Path: [Production]
Press to access the screen at which automatic operation can be executed.
Revision history:
Commands >> Command Descriptions
SYS-CP842-1.0E 5-51
Production Operation
Command Path: [Operation] - [Production]
Press to set the operation mode to Production.
Revision history:
Program Main
Command Path: [Program]
Press to access the screen at which program related settings can be made.
Revision history:
Program Backup Data Manager
Command Path: [Maintenance] - [Data Manager] - [Program Backup]
Press to access the screen at which programs can be backed up.
Revision history:
Program Coordinates Position
Command Path: [Position] - [Program Coordinates]
Press to display the numeric keypad for specification of the coordinates to which the
selected axis (selected at the commands [X-axis] and [Y-axis]) will be moved.
Revision history:
Program Editor Maintenance
Command Path: [Maintenance] - [Program Editor]
Press to access the screen at which program related settings can be made.
Revision history:
Read Operation
Command Path: [Operation] - [Read]
Press to enable the detection of skip marks.
Revision history:
