Commands >> Command Descriptions
SYS-CP842-1.0E 5-35
Edit Host Network
Command Path: [Maintenance] - [System] - [Network] - [Edit Host]
Press to edit the host file.
Selecting this command opens the host file in Notepad.
Revision history:
Enabled Production
Command Path: [Production] - [Enabled]
Press to enable remote start settings.
Revision history:
English/Japanese Operator Settings
Command Path: [Maintenance] - [Operator] - [English/Japanese]
Press to select the desired display language.
Revision history:
Enter Nozzle Check
Command Path: [Nozzle Check] - [Enter]
Press to enable the START command when checking the nozzle condition.
Select at least one nozzle and one inspection item to enable this command.
Revision history:
Error Pass Recovery
Command Path: [Recovery] - [Error Pass]
Press to continue production in response to a part error.
Revision history:
Commands >> Command Descriptions
5-36
SYS-CP842-1.0E
Errors Nozzle Check Conditions
Command Path: [Maintenance] - [Configuration] - [Nozzle Skip Conditions] -
[Errors]
Press to select a vision error as a nozzle skip factor.
Revision history:
Error Stop Recovery
Command Path: [Recovery] - [Error Stop]
Press to execute a cycle stop in response to a part error.
Revision history:
Finish All Panels Production
Command Path: [Production] - START button - [Finish All Panels]
Press to stop the machine only after all panels in the machine have been completed
and unloaded from the machine.
Revision history:
Finish Current Panels Production
Command Path: [Production] - START button - [Finish Current Panels]
Press to stop the machine after the panels currently being produced are completed
and unloaded.
Revision history:
Floppy Disk Operator Data Manager
Command Path: [Maintenance] - [Operator] - [Data Manager] - [Floppy Disk]
Press to read operator settings from, and copy operator settings to the floppy disk.
Revision history:
Handy Terminal Machine Configuration Data
Command Path: [Maintenance] - [Configuration] - [Handy Terminal]
Press to access the screen at which Handy Terminal related settings can specified.
Revision history:
Commands >> Command Descriptions
SYS-CP842-1.0E 5-37
Hard Disk Operator Data Manager
Command Path: [Maintenance] - [Operator] - [Data Manager] - [Hard Disk]
Press to read operator settings from, and copy operator settings to the hard disk.
Revision history:
Holder Center Nozzle Check
Command Path: [Nozzle Check] - [Holder Center]
Press to select holder center as an item for nozzle measurement.
Revision history:
Host Command bar (All Screens)
Command Path: [Host]
Press to display a dialog box for selection of the communication and control statuses.
Revision history:
Idle Operation
Command Path: [Operation] - [Idle]
Press to set the production mode to Idle.
Revision history:
Ignore Operation
Command Path: [Operation] - [Ignore]
Press to operate the machine without reading skip marks.
Revision history:
Image Buffer Vision system
Command Path: [Maintenance] - [Vision System] - [Image Buffer]
Press to access the screen at which the images stored in the image buffer can be
viewed.
Revision history:
