Commands >> Command Descriptions
SYS-CP842-1.0E 5-27
Board Skip Data Main
Command Path: [Board Skip Data]
Press to access the board skip setting screen.
Revision history:
Board Skip Data Production
Command Path: [Production] - START button - [Board Skip Data]
Press to change the display during production to board skip related information.
Revision history:
Board Skip Settings Machine Configuration Data
Command Path: [Maintenance] - [Configuration] - [Board Skip Settings]
Press to access the screen at which settings can be made for machine operation after
the detection of board skip marks.
Revision history:
Brightness Nozzle Check
Command Path: [Nozzle Check] - [Brightness]
Press to specify brightness as one of the nozzle check inspection items.
Revision history:
Brightness Deviation Nozzle Check Limits
Command Path: [Nozzle Check] - [Nozzle Check Limits] - [Brightness Deviation]
Press to edit the brightness standard deviation tolerance level.
Revision history:
Calibration Maintenance
Command Path: [Maintenance] - [Calibration]
Press to access the screen at which the commands related to machine calibration can
be selected.
Revision history:
Commands >> Command Descriptions
5-28
SYS-CP842-1.0E
Calibration Data System Backup
Command Path: [Maintenance] - [Data Manager] - [System Backup] - [Calibration
Data]
Press to select calibration data for backup.
Revision history:
Calibration Editor Machine Calibration Data
Command Path: [Maintenance] - [Calibration] - [Calibration Editor]
Press to access the screen at which machine calibration data items can be edited.
Revision history:
Caliper Trace Settings
Command path: [Maintenance] - [Vision System] - [Image Buffer] - [Trace Settings] -
[Caliper]
Press to display caliper information.
Revision history:
Carrier Clamp Loader Maintenance
Command Path: [Panel Loader] - [Loader Maintenance] - [Carrier Clamp]
Press to clamp the carrier at the selected side of the machine. Press the START but-
ton to execute.
Revision history:
Carrier Extend Loader Maintenance
Command Path: [Panel Loader] - [Loader Maintenance] - [Carrier Extend]
Press to advance the carrier at the selected side of the machine. Press the START but-
ton to execute.
Revision history:
Commands >> Command Descriptions
SYS-CP842-1.0E 5-29
Carrier Retract Loader Maintenance
Command Path: [Panel Loader] - [Loader Maintenance] - [Carrier Retract]
Press to retract the carrier at the selected side of the machine. Press the START but-
ton to execute.
Revision history:
Carrier Unclamp Loader Maintenance
Command Path: [Panel Loader] - [Loader Maintenance] - [Carrier Unclamp]
Press to unclamp the carrier at the selected side of the machine. Press the START
button to execute.
Revision history:
Change Recovery
Command Path: [Recovery] - [Change]
Press to change the number of times the machine will attempt a recovery.
Selecting this command displays the Numeric Keypad. Input a value and press [OK].
Revision history:
Change Name Operator Settings
Command Path: [Maintenance] - [Operator] - [Change Name]
Press to access the screen at which operator names can be changed.
Revision history:
Changeover Operation
Command Path: [Operation] - [Changeover]
Press to set the device table mode to Changeover.
Revision history:
