Commands >> Command Descriptions
5-46
SYS-CP842-1.0E
Nozzle Skip Conditions Machine Configuration Data
Command Path: [Maintenance] - [Configuration] - [Nozzle Skip Conditions]
Press to access the screen at which the conditions for nozzle skips can be selected and
cleared.
Revision history:
Operation Main
Command Path: [Operation]
Press to access the screen at which operation mode settings are made.
Revision history:
Operator Maintenance
Command Path: [Maintenance] - [Operator]
Press to access the screen at which the display languages can be selected and other
operator settings can be copied, deleted and loaded or saved from or to the hard disk or
floppy disk.
Revision history:
Options Maintenance
Command Path: [Maintenance] - [Options]
Press to access the screen at which options (Status Reset, Warranty) can be selected.
Revision history:
Origin Pos Offset Machine Calibration Data
Command Path: [Maintenance] - [Calibration] - [Origin Pos Offset]
Press to access the screen at which the axes origin positions can be set in calibration
data.
Revision history:
Commands >> Command Descriptions
SYS-CP842-1.0E 5-47
Out-carrier Pick-up Loader Maintenance
Command Path: [Panel Loader] - [Loader Maintenance] - [Out-carrier Pick-up]
Press to unload the panel on the main conveyor to the out-carrier. Press the START button
to execute.
Revision history:
Out-lifter Pick-up Loader Maintenance
Command Path: [Panel Loader] - [Loader Maintenance] - [Out-lifter Pick-up]
Press to unload the panel on the out-carrier to the out-lifter. Press the START button
to execute.
Revision history:
Output Signal ON/OFF I/O Check
Command Path: [Maintenance] - [I/O check] - [Standard]/[Servo] - [Output signal
ON/OFF]
Press to turn the selected output signal on or off.
Use the arrow-buttons to scroll up and down through the list of input and output sig-
nals.
Revision history:
Out-side Loader Maintenance
Command Path: [Panel Loader] - [Loader Maintenance] - [Out-side]
Press to select the panel unloading side of the machine as the target for subsequent
loader commands.
Revision history:
Pallet Change Pos Machine Calibration Data
Command Path: [Maintenance] - [Calibration] - [Pallet Change Pos]
Press to access the screen at which the pallet change position can be set in calibration
data.
Revision history:
Commands >> Command Descriptions
5-48
SYS-CP842-1.0E
Panel Loader Main
Command Path: [Panel Loader]
Press to access the screen at which panels can be loaded or flushed out, and the lifter
can be raised or lowered.
Revision history:
Part Data Basic Configuration
Command Path: [Maintenance] - [Configuration] - [Basic] - [Part Data]
Press to perform a changeover to the next device in accordance with the conditions
specified in Part data.
Revision history:
Part Data Recovery
Command Path: [Recovery] - [Part Data]
Press to use the recovery limits set in part data.
Revision history:
Parts Camera Resolution Machine Calibration Data
Command Path: [Maintenance] - [Calibration] - [Parts Camera Resolution]
Press to access the screen at which the parts camera resolution can be measured.
Revision history:
Part Rejection Main
Command Path: [Part Rejection]
Press to access the screen at which the part currently held by the placing head can be
rejected.
Revision history:
Parts Miss Basic Configuration
Command Path: [Maintenance] - [Configuration] - [Basic] - [Parts Miss]
Press to execute a forced device check after pick-up errors.
Revision history:
