Commands >> Command Descriptions
5-28
SYS-CP842-1.0E
Calibration Data System Backup
Command Path: [Maintenance] - [Data Manager] - [System Backup] - [Calibration
Data]
Press to select calibration data for backup.
Revision history:
Calibration Editor Machine Calibration Data
Command Path: [Maintenance] - [Calibration] - [Calibration Editor]
Press to access the screen at which machine calibration data items can be edited.
Revision history:
Caliper Trace Settings
Command path: [Maintenance] - [Vision System] - [Image Buffer] - [Trace Settings] -
[Caliper]
Press to display caliper information.
Revision history:
Carrier Clamp Loader Maintenance
Command Path: [Panel Loader] - [Loader Maintenance] - [Carrier Clamp]
Press to clamp the carrier at the selected side of the machine. Press the START but-
ton to execute.
Revision history:
Carrier Extend Loader Maintenance
Command Path: [Panel Loader] - [Loader Maintenance] - [Carrier Extend]
Press to advance the carrier at the selected side of the machine. Press the START but-
ton to execute.
Revision history:
Commands >> Command Descriptions
SYS-CP842-1.0E 5-29
Carrier Retract Loader Maintenance
Command Path: [Panel Loader] - [Loader Maintenance] - [Carrier Retract]
Press to retract the carrier at the selected side of the machine. Press the START but-
ton to execute.
Revision history:
Carrier Unclamp Loader Maintenance
Command Path: [Panel Loader] - [Loader Maintenance] - [Carrier Unclamp]
Press to unclamp the carrier at the selected side of the machine. Press the START
button to execute.
Revision history:
Change Recovery
Command Path: [Recovery] - [Change]
Press to change the number of times the machine will attempt a recovery.
Selecting this command displays the Numeric Keypad. Input a value and press [OK].
Revision history:
Change Name Operator Settings
Command Path: [Maintenance] - [Operator] - [Change Name]
Press to access the screen at which operator names can be changed.
Revision history:
Changeover Operation
Command Path: [Operation] - [Changeover]
Press to set the device table mode to Changeover.
Revision history:
Commands >> Command Descriptions
5-30
SYS-CP842-1.0E
Changeover Checks Machine Configuration Data
Command Path: [Maintenance] - [Configuration] - [Changeover Checks]
Press to access the screen at which settings can be made to automatically activate
functions after changeover.
Revision history:
Change Pallet Main
Command Path: [Change Pallet]
Press to access the screen at which pallet change commands and instructions can be
accessed.
Revision history:
Chg Scheduled Panels Program
Command Path: [Program] - [Chg Scheduled Panels]
Press to change the number of scheduled panels for the selected program.
Selecting this command displays the Numeric Keypad. Input a value and press [OK].
Revision history:
Clamp Panel Loader
Command Path: [Panel Loader] - [Clamp]
Press to clamp the panel that has been loaded onto the main conveyor.
Press the START button to execute the operation.
Revision history:
Clear Completed Panels Program
Command Path: [Program] - [Clear Completed Panels]
Press to set the Completed Panels item for the selected program to 0.
Revision history:
