I/O Map >> Standard Input and Output Signals SYS-CP842-1.0E 6-9 X0CF OUT-CARRIER RETRACTED LIMIT CHECK Out-carrier retract end Retracted limit: O X0D0 OUT-LIFTER UPPER LIMIT CHECK Out -lifter upper limi t Upper lim…
I/O Map >> Standard Input and Output Signals
6-8
SYS-CP842-1.0E
X0B9 IN-CARRIER FORWARD LIMIT
CLAMP CHECK (FIXED RAIL)
In-carrier advance end clamp
(Fixed rail)
Carrier closed: O
X0BA IN-CARRIER FORWARD LIMIT
CLAMP CHECK (ADJUSTABLE RAIL)
In-carrier advance end clamp
(Adjustable rail)
Carrier closed: O
X0BB IN-CARRIER RETRACT LIMIT
UNCLAMP (FIXED RAIL)
In-carrier retract end unclamp
(Fixed rail)
Carrier opened: O
X0BC IN-CARRIER RETRACT LIMIT
UNCLAMP CHECK (ADJUSTABLE
RAIL)
In-carrier retract end unclamp
(Adjustable rail)
Carrier opened: O
X0BD IN-CARRIER FORWARD LIMIT
UNCLAMP CHECK (FIXED RAIL)
In-carrier advance end unclamp
(Fixed rail)
Carrier opened: O
X0BE IN-CARRIER FORWARD LIMIT
UNCLAMP CHECK (ADJUSTABLE
RAIL)
In-carrier advance end unclamp
(Adjustable rail)
Carrier opened: O
X0BF XY-TABLE INSIDE LOADING
POSITION CHECK
XY-table loading position (inside) Loading position: O
X0C0 ADJUSTING RAIL ENGAGEMENT
CHECK (IN)
Adjusting rail engagement (inside) Rail clutching: O
X0C1 IN-CONVEYOR 1ST PANEL
STOPPER UPPER LIMIT CHECK
In-conveyor 1st panel stopper upper
limit
Stopper raised: O
X0C2 IN-CONVEYOR 1ST PANEL
STOPPER LOWER LIMIT CHECK
In-conveyor 1st panel stopper lower
limit
Stopper lowered: O
X0C3 THERMO FUSE OK Thermo fuse OK Normal: O
X0C4 OUT-CONVEYOR 2ND PANEL
STOPPER UPPER LIMIT CHECK
Out-conveyor 2nd panel stopper upper
limit
Stopper raised: O
X0C5 OUT-CONVEYOR 2ND PANEL
STOPPER LOWER LIMIT CHECK
Out-conveyor 2nd panel stopper lower
limit
Stopper lowered: O
X0C6 Not used
X0C7 OUT-CONVEYOR 1 PANEL ARRIVAL
CHECK
Out-conveyor 1 panel arrival Panel present: O
X0C8 Not used
X0C9 OUT-CONVEYOR 2 PANEL ARRIVAL
CHECK
Out-conveyor 2 panel arrival Panel present: O
X0CA PANEL INTERVAL BETWEEN OUT-
CONVEYOR 1 AND 2
Panel interval between out-conveyor 1
and 2
Panel present: X
X0CB OUT-CONVEYOR UNLOADER
PANEL ARRIVAL CHECK
Out-conveyor unloader panel arrival Panel present: O
X0CC OUT-CARRIER FORWARD LIMIT
PANEL CHECK (1)
Out-carrier advance end panel check 1 Panel present: O
X0CD OUT-CARRIER FORWARD LIMIT
PANEL CHECK (2)
Out-carrier advance end panel check 2 Panel present: O
X0CE OUT-CARRIER FORWARD LIMIT
CHECK
Out-carrier advance end Advanced limit: O
Address Signal Name Description Signal Status at I/O
Screen
I/O Map >> Standard Input and Output Signals
SYS-CP842-1.0E 6-9
X0CF OUT-CARRIER RETRACTED LIMIT
CHECK
Out-carrier retract end Retracted limit: O
X0D0 OUT-LIFTER UPPER LIMIT CHECK Out-lifter upper limit Upper limit: O
X0D1 OUT-LIFTER LOWER LIMIT CHECK Out-lifter lower limit Lower limit: O
X0D2 OUT-CARRIER RETRACT LIMIT
CLAMP CHECK (FIXED RAIL)
Out-carrier retract end clamp
(Fixed rail)
Carrier closed: O
X0D3 OUT-CARRIER RETRACT LIMIT
CLAMP CHECK (ADJUSTABLE RAIL)
Out-carrier retract end clamp
(Adjustable rail)
Carrier closed: O
X0D4 OUT-CARRIER FORWARD LIMIT
CLAMP CHECK (FIXED RAIL)
Out-carrier advance end clamp
(Fixed rail)
Carrier closed: O
X0D5 OUT-CARRIER FORWARD LIMIT
CLAMP CHECK (ADJUSTABLE RAIL)
Out-carrier advance end clamp
(Adjustable rail)
Carrier closed: O
X0D6 OUT-CARRIER RETRACT LIMIT
UNCLAMP CHECK (FIXED RAIL)
Out-carrier retract end unclamp
(Fixed rail)
Carrier opened: O
X0D7 OUT-CARRIER RETRACT LIMIT
UNCLAMP CHK (ADJUSTABLE
RAIL)
Out-carrier retract end unclamp
(Adjustable rail)
Carrier opened: O
X0D8 OUT-CARRIER FORWARD LIMIT
UNCLAMP CHECK (FIXED RAIL)
Out-carrier advance end unclamp
(Fixed rail)
Carrier opened: O
X0D9 OUT-CARRIER FORWARD LIMIT
UNCLAMP CHK (ADJUSTABLE
RAIL)
Out-carrier advance end unclamp
(Adjustable rail)
Carrier opened: O
X0DA XY TABLE OUTSIDE LOADING
POSITION CHECK
XY-table loading position (outside) Loading position: O
X0DB ADJUSTING RAIL ENGAGEMENT
CHECK (OUT)
Adjusting rail engagement (outside) Rail clutching: O
X0DC ADJUSTING RAIL ENGAGEMENT
CHECK (CENTER)
Adjusting rail engagement (center) Rail clutching: O
X0DD Not used
X0DE Not used
X0DF RESERVED Reserved
Address Signal Name Description Signal Status at I/O
Screen
I/O Map >> Standard Input and Output Signals
6-10
SYS-CP842-1.0E
6.1.2 Standard Output Signals
Output-1
Address Signal Name Description
Y000 START SWITCH LAMP ON1 Side1 Start switch lamp on
Y001 READY ON1 LAMP ON Side1 Ready on lamp on
Y002 BUZZER ON1 Side1 Buzzer on
Y003 Not used
Y004 SIGNAL TOWER RED ON Signal tower (red lamp)
Y005 SIGNAL TOWER YELLOW ON Signal tower (yellow lamp)
Y006 SIGNAL TOWER BLUE ON Signal tower (blue lamp)
Y007 SIGNAL TOWER RED BLINK Signal tower (red flash)
Y008 SIGNAL TOWER YELLOW BLINK Signal tower (yellow flash)
Y009 SIGNAL TOWER BLUE BLINK Signal tower (blue flash)
Y00A START SWITCH LAMP ON2 Side2 Start switch lamp on
Y00B READY ON2 LAMP ON Side2 Ready on lamp on
Y00C BUZZER ON2 Side2 Buzzer on
Y00D Side2 ENABLE Side 2 Enable
Y00E CAM AXIS ABS SETUP Cam-axis ABS setup
Y00F TIME COUNTER ON Time counter on
Y010 MASTER ON Master on
Y011 OVERTRAVEL CUT Cut overtravel control
Y012 FRONT DOOR LOCK Front door lock
Y013 REAR DOOR D1 LOCK Rear door D1 lock
Y014 REAR DOOR MIDDLE LOCK Rear door middle lock
Y015 REAR DOOR D2 LOCK Rear door D2 lock
Y016 SHUTDOWN Shutdown
Y017 FIDUCIAL LAMP ON Fiducial lamp on
Y018 PANEL REQUEST Panel request signal from previous stage
Y019 BOARD AVAILABLE Panel available signal to next stage
Y01A FOLLOW PERMIT OUTPUT Permit follow up (HELPS)
Y01B X AXIS ABS SETUP X-axis ABS setup
Y01C Y AXIS ABS SETUP Y-axis ABS setup
Y01D Z AXIS ABS SETUP Z-axis ABS setup
Y01E PQ AXIS ABS SETUP PQ-axis ABS setup
Y01F FQ AXIS ABS SETUP FQ-axis ABS setup
Y020 FRONTLIGHT 1 ON Frontlight 1 on
Y021 FRONTLIGHT 2 ON Frontlight 2 on
