Safety >> About Symbols
SYS-CP842-1.0E 2-1
2. Safety
Fuji machines are designed and produced with safety as one of our main consider-
ations. However, even a perfectly designed machine can be damaged, or someone can
still be injured if the user does not follow the safety rules. It is the responsibility of
the user to make sure all safety rules are followed during operation and maintenance.
Be sure to read these safety rules before operating the machine. Keep this manual
close at hand when operating the machine.
2.1 About Symbols
This section provides an explanation of the relevant safety precautions to be adhered
to by both operators and those responsible for maintaining the machine. An explana-
tion of the warning labels attached to the machine is also provided.
This manual employs the use of descriptive symbols and provides details of the level of
danger involved in certain operations to accompany the explanations of machine warn-
ing labels and safety related items. Be sure you understand the meanings of these sym-
bols before reading the manual.
2.1.1 Hazard Definitions
Examples of Symbols Used
Symbol Definition
DANGER
Failure to observe this hazard warning will lead to severe
injury or death.
WARNING
Failure to observe this hazard warning may lead to severe
injury or death.
CAUTION
Failure to observe this hazard warning may lead to per-
sonal injury or damage to the machine.
Symbol Explanation
Hazard
A triangle is used to draw your attention to a hazard. The symbol
inside the triangle indicates the nature of the hazard (in this case,
electrical shock).
Prohibition
A circle with a diagonal line is used to draw your attention to an
operation that is prohibited. The symbol inside the circle indicates
the nature of the operation (in this case, disassembly).
A circle with an exclamation mark is used to draw your attention to
to a mandatory action. In other words, you are required to carefully
carry out the given instructions.
Safety >> Safety Rules for All Machine Types
2-2
SYS-CP842-1.0E
2.2 Safety Rules for All Machine Types
DANGER
Do not approach moving parts during automatic or manual oper-
ation.
z Do not place hands or other body parts inside the machine
during automatic operation or positioning. Body parts or
clothing may be caught in the machine causing personal
injury.
WARNING
Do not operate the machine with the safety covers or doors
open.
z Do not leave covers or safety doors open, except during
adjustment.
z hen adjustments are completed, return the covers and
doors to their original (closed) position...
z When safety covers or doors are removed, body parts or
clothing may be caught in the machine causing personal
injury. Always be sure to replace the safety covers or
doors.
Always verify the position of the EMERGENCY STOP buttons
before operating the machine.
z Always be aware of the positions of the EMERGENCY
STOP buttons so that they can be pressed quickly in case
of an emergency.
Check the safety functions before starting operation.
z Before starting the machine check the operation of the
EMERGENCY STOP button, the safety switches on the
acrylic covers, the safety switch on the rear fence gate, the
optical sensors on the rear fence and all other machine
safety features.
z Contact a Fuji serviceman immediately if any of the safety
functions fails.
