- 5 4 - B.A.IN Ready OUT I N sensor WAIT sensor STOP sensor C.OUT sensor OUT sensor B U U P sensor B U D N sensor Stopper Backup External shape cramp 1 ( X ) I N motor CENT motor OUT motor Ready I N B.A.OUT Continuous pr…
- 53 -
P1 P2
T1 T2
l1 l2
L
H
O
20.8 mm
H≒400 mm/s fi ≒1587 pps
L≒56 mm/s fi ≒223 pps
Resolution of the CENT motor = 0.252 mm/P
Where T1 = 130 ms
Where T2 = 430 ms
Board
Stopper
Stop sensor
Adjust the position of the STOP sensor so that the
board touches the stopper at approximate this speed.
l1 = = 26 mm
400 · 0.13
2,
P1 = ≒103 pulse
26
0.252
l2 = 56 · 0.43≒24 mm , P2 = ≒96 pulse
24
0.252
(1)
Carrying in the first board for continuous production
B.A.IN
Ready OUT
IN sensor
WAIT sensor
STOP sensor
C.OUT sensor
OUT sensor
BU UP sensor
BU DN sensor
Stopper
Backup
External shape
cramp 1 (X)
IN motor
CENT motor
OUT motor
Ready IN
B.A.OUT
Continuous
production (Carriage
start)
External shape
cramp 2 (Y)
Carriage, completed
CENT motor speed
- 54 -
B.A.IN
Ready OUT
IN sensor
WAIT sensor
STOP sensor
C.OUT sensor
OUT sensor
BU UP sensor
BU DN sensor
Stopper
Backup
External shape
cramp 1 (X)
IN motor
CENT motor
OUT motor
Ready IN
B.A.OUT
Continuous
production
(Carriage start)
External shape
cramp 2 (Y)
This chart shows that board A whose production has been completed is carried out when the next stage is set busy.
(2)
- 55 -
This chart shows that board A whose production has been completed is carried out when the next stage is set ready.
B.A.IN
Ready OUT
IN sensor
WAIT sensor
STOP sensor
C.OUT sensor
OUT sensor
BU UP sensor
BU DN sensor
Stopper
Backup
External shape
cramp 1 (X)
IN motor
CENT motor
OUT motor
Ready IN
B.A.OUT
Continuous
production
(Carriage start)
External shape
cramp 2 (Y)
(3)
