- 5 9 - This chart shows that board C has been carried in from the I N buffer when boards are set both i n the OUT buffer and the centering station. (7) B.A.IN Ready OUT I N sensor WAIT s e nsor STOP sensor C.OUT sensor …
- 58 -
This chart shows that production of board A has been completed when board B is set standby in the IN buffer and the next stage is set ready.
(6)
B.A.IN
Ready OUT
IN sensor
WAIT sensor
STOP sensor
C.OUT sensor
OUT sensor
BU UP sensor
BU DN sensor
Stopper
Backup
External shape
cramp 1 (X)
IN motor
CENT motor
OUT motor
Ready IN
B.A.OUT
Continuous
production
(Carriage start)
External shape
cramp 2 (Y)
Carriage, completed
- 59 -
This chart shows that board C has been carried in from the IN buffer when boards are set both in the OUT buffer and the centering station.
(7)
B.A.IN
Ready OUT
IN sensor
WAIT sensor
STOP sensor
C.OUT sensor
OUT sensor
BU UP sensor
BU DN sensor
Stopper
Backup
External shape
cramp 1 (X)
IN motor
CENT motor
OUT motor
Ready IN
B.A.OUT
External shape
cramp 2 (Y)
- 60 -
This chart shows that production of board B has been completed before board A starts.
(8)
B.A.IN
Ready OUT
IN sensor
WAIT sensor
STOP sensor
C.OUT sensor
OUT sensor
BU UP sensor
BU DN sensor
Stopper
Backup
External shape
cramp 1 (X)
IN motor
CENT motor
OUT motor
Ready IN
B.A.OUT
External shape
cramp 2 (Y)
Continuous
production
(Carriage start)
Carriage, completed
This means that the OUT motor continues to turn until board A is output if the software is set ineffectiv
e
at an
y
timin
g
if it is set effective for the time that the software can be sam
p
led.
20 ms or more
