Communication Interfaces
86
VTK-TR-BA-072e-1 - User Manual MDS 358X Series
RS-232C commands Reaction time (ms)
For baud rate:
9600 bits/s 115200 bits/s
35. SYSTEM:SHOW:ACTTEMP
90
70
36. SYSTEM:DOSOKDELAY:OFF
110
80
37. SYSTEM:DOSOKDELAY:ON
110
80
38. SYSTEM:SINGLEDOSOK:SETUP
110
90
39. SYSTEM:SINGLEDOSOK:PULSE
110
80
40. SYSTEM:PASSWORD:<your password>
100
70
41. SYSTEM:PASSWORD:OFF
100
80
42. SYSTEM:PASSWORD:ON
100
80
43. SYSTEM:PASSWORD:SET:<your password>
110
90
44. SYSTEM:AUXILIARYMODE:OFF
100
70
45. SYSTEM:AUXILIARYMODE:ON
100
70
46. TRIGGER:ASET:?
390
340
47. TRIGGER:ASET:<RI>,<OT>,<FA>,<NL>,<NP>,<DL>
130
90
48. TRIGGER:ASET:<RI>,<OT>,<FA>,<NL>,<NP>,<DL>,1
150
100
49. STRIGGER:ASET:<RI>,<OT>,<FA>,<NL>,<NP>,<DL>
440
360
50. STRIGGER:ASET:<RI>,<OT>,<FA>,<NL>,<NP>,<DL>,1
450
370
51. VALVE:UP
80
70
52. VALVE:DOWN
80
70
53. VALVE:AOPEN
80
70
54. VALVE:AOPEN:<RI>,<OT>,<FA>,<NL>,<NP>,<DL>
130
90
55. VALVE:AOPENS<setup no.>
80
70
56. SVALVE:AOPEN
390
340
57. SVALVE:AOPEN:<RI>,<OT>,<FA>,<NL>,<NP>,<DL>
430
350
58. SVALVE:AOPENS<setup no.>
390
340
59. WRITE:LCD:<text>
110
80
60. TAPPET:SET:<value>
190
180
61. TAPPET:CLEAR
190
180
62. NOZZLE:SET:<value>
200
180
63. NOZZLE:CLEAR
190
180
64. SCENARIO:STATUS
690
340
65. SCENARIO:OFF
100
80
66. SCENARIO:ON
100
80
67. SCENARIO:PLCSTOP:1:OFF
140
120
68. SCENARIO:PLCSTOP:1:ON
140
120
69. SCENARIO:SAVE:<scenario no.>:<values>
280
130
70. SCENARIO:READ:<scenario no.>
690
340
Communication Interfaces
VTK-TR-BA-072e-1 - User Manual MDS 358X Series
87
RS-232C commands Reaction time (ms)
For baud rate:
9600 bits/s 115200 bits/s
71. SETUP:ASAVE:<setup no.>:<RI>,<OT>,<FA>,<NL>,<NP>,<DL>
570
530
72. SETUP:AREAD:<setup no.>
390
340
73. BAUDRATE:0/1/2/3/4
80
70
74. GETTD
80
70
75. MDC:RESTART
190
170
Communication Interfaces
88
VTK-TR-BA-072e-1 - User Manual MDS 358X Series
8.1.2.2 Explanations
0
1 *ESR? ESR? = Event Status Register Query
Description:
This command shows the latest error codes created by the system, starting
with the latest event. At the most 50 error messages will be shown.
Each error messages also includes the valve ID (if known) and a time and
date stamp. If the RTC of the MDC is defect, the value will be given as
“00:00:00 2014-01-01”.
Example:
Input:
*ESR?
Result:
List of the (up to 50) latest error messages
Return:
8 199 valve error 08FU04 09:16:38 2018-01-21
9 101 wrong valve 08FU04 09:16:21 2018-01-21
2 *ESR2? ESR2? = Event Status Register Query 2
Description:
This command shows the latest error codes created by the system, starting
with the latest event. There will be shown a max of 50 error messages.
Each error messages also includes the valve ID (if known) and a time and
date stamp. If the RTC of the MDC is defect, the value will be given as
“00:00:00 2014-01-01”. Additionally the parameters of setups 0 to 3 before
the error are listed.
Example:
Input:
*ESR2?
Result:
List of the (up to 50) latest error messages with parameters
Return:
20 199 valve error 000000 09:16:38 2018-01-21
0, 0, 0, 0, 0, 0
0, 0, 0, 0, 0, 0
0, 0, 0, 0, 0, 0
0, 0, 0, 0, 0, 0
27 101 wrong valve 08FU04 09:16:21 2018-01-21
30, 5, 30, 80, 1, 20
50, 20, 20, 80, 1, 100
50, 20, 20, 80, 1, 100
50, 20, 20, 80, 1, 100
3 *IDN? IDN? = Identification Query
Description:
Device specific information, formatted as follows: type (hv or lv, high
viscosity or low viscosity systems), software version. Important for contact
with our Technical Support.
Example:
Input:
*IDN?
Result:
Micro Dispenser HV, 4085AA1-1
Return:
Micro Dispenser HV, 4085AA1-1
4 *OPC? OPC? = Operation Complete Query
Description:
Monitoring the last trigger impulses. After this, the counter is cleared to
zero.
Example:
Input:
*OPC?
Result:
Number of the last pulses. Clears the counter to zero.
Return:
6699
