Communication Interfaces 88 VTK - TR -BA- 072e - 1 - User Manua l MDS 358X S eries 8.1.2.2 E xplan ations 0 1 *ESR? ESR? = Event S tat us Reg is ter Quer y Descript ion: This command shows the la test err or codes create…

100%1 / 195
Communication Interfaces
VTK-TR-BA-072e-1 - User Manual MDS 358X Series
87
RS-232C commands Reaction time (ms)
For baud rate:
9600 bits/s 115200 bits/s
71. SETUP:ASAVE:<setup no.>:<RI>,<OT>,<FA>,<NL>,<NP>,<DL>
570
530
72. SETUP:AREAD:<setup no.>
390
340
73. BAUDRATE:0/1/2/3/4
80
70
74. GETTD
80
70
75. MDC:RESTART
190
170
Communication Interfaces
88
VTK-TR-BA-072e-1 - User Manual MDS 358X Series
8.1.2.2 Explanations
0
1 *ESR? ESR? = Event Status Register Query
Description:
This command shows the latest error codes created by the system, starting
with the latest event. At the most 50 error messages will be shown.
Each error messages also includes the valve ID (if known) and a time and
date stamp. If the RTC of the MDC is defect, the value will be given as
“00:00:00 2014-01-01”.
Example:
Input:
*ESR?
Result:
List of the (up to 50) latest error messages
Return:
8 199 valve error 08FU04 09:16:38 2018-01-21
9 101 wrong valve 08FU04 09:16:21 2018-01-21
2 *ESR2? ESR2? = Event Status Register Query 2
Description:
This command shows the latest error codes created by the system, starting
with the latest event. There will be shown a max of 50 error messages.
Each error messages also includes the valve ID (if known) and a time and
date stamp. If the RTC of the MDC is defect, the value will be given as
“00:00:00 2014-01-01”. Additionally the parameters of setups 0 to 3 before
the error are listed.
Example:
Input:
*ESR2?
Result:
List of the (up to 50) latest error messages with parameters
Return:
20 199 valve error 000000 09:16:38 2018-01-21
0, 0, 0, 0, 0, 0
0, 0, 0, 0, 0, 0
0, 0, 0, 0, 0, 0
0, 0, 0, 0, 0, 0
27 101 wrong valve 08FU04 09:16:21 2018-01-21
30, 5, 30, 80, 1, 20
50, 20, 20, 80, 1, 100
50, 20, 20, 80, 1, 100
50, 20, 20, 80, 1, 100
3 *IDN? IDN? = Identification Query
Description:
Device specific information, formatted as follows: type (hv or lv, high
viscosity or low viscosity systems), software version. Important for contact
with our Technical Support.
Example:
Input:
*IDN?
Result:
Micro Dispenser HV, 4085AA1-1
Return:
Micro Dispenser HV, 4085AA1-1
4 *OPC? OPC? = Operation Complete Query
Description:
Monitoring the last trigger impulses. After this, the counter is cleared to
zero.
Example:
Input:
*OPC?
Result:
Number of the last pulses. Clears the counter to zero.
Return:
6699
Communication Interfaces
VTK-TR-BA-072e-1 - User Manual MDS 358X Series
89
5 ADJUST:START
Description:
Sending this command causes the adjust to be executed at once. This
procedure checks on the position of the nozzle insert with respect to the
tappet. It is required during each initial start-up and after replacing the
nozzle unit.
For further information read paragraph 8.2.3, page 117.
Example:
Input:
ADJUST:START
Result:
The adjust is initiated.
Return:
Adjust Screw OUT Press Enter
6 ADJUST:OFFSET:?
Description:
This command gives the current value of the adjust offset (see
paragraph 7.12, page 75).
The value can be between -5 and 5. The value 0 means, the adjust offset is
deactivated.
Example:
Input:
ADJUST:OFFSET:?
Result:
The current value of the adjust offset is returned.
Return:
5
7 ADJUST:OFFSET:<offset value>
Description:
This command sets the value for the adjust offset (see paragraph 7.12,
page 75).
You can enter integer values between -5 and 5. With 0 you deactivate the
adjust offset.
Example:
Input:
ADJUST:OFFSET:5
Result:
The value of the adjust offset is set (here: to 5).
Return:
OK
8 ADJUST:CALIBRATION:?
Description:
This command gives the status of the (remote) adjust and the current
adjust value. The response to this command contains seven numerical
values. You can ignore the first six parameters limit at 0 %, limit at 100 %,
difference, reference value, last mean value and total value). They are only
there for our support, if there is an error with the (remote) adjust.
The last parameter sent is the adjust value in percent. Be aware that the
given value is the actual percentage value, multiplied by 10. Therefore, a
given value of 8 represents an adjust value of 0.8 %.
Example:
Input:
ADJUST:CALIBRATION:?
Result:
The status of the (remote) adjust is given, including the
current adjust value.
Return:
151285, 47623, 103662, 150836, 108654, 42182, 8
9 ADJUST:CALIBRATION:ON
Description:
This command activates the adjust, so that you can perform it as a remote
adjust.
Example:
Input:
ADJUST:CALIBRATION:ON
Result:
The adjust is activated.
Return:
Adjust ON
