Chapter 5 Libraries

5-37

Click the <Full Screen Mode> button.

Note: When the <Full Screen Mode> button is clicked, all the eight heads can be displayed in the

monitor as shown below.

Note: In the mark Image Library window, the image can be zoomed in and out as well as in this

window.

Chapter 5 Libraries

5-38

5-1-3 Vision Processing and Libraries

5-1-3-1 Vision-related Libraries

Component library

Pickup data

Placement & Mark data

Fiducial data &

Bad mark data

Image library

Nozzle library

Nozzle No.

Image code

Mark code

Component code

Code: In the Placement&Mark Data editor, enter a component code for a component process

(placement) step, a mark code for a mark process (fiducial/bad mark) step.

5-1-3-2 Exporting settings to Comp-LB at data-saving of Image-LB

When you open an Image library recode by double-clicking Image code name in Component

Library, you will see the following messages when you tried to save the Image library after

editing.

If you click [Yes] here, the new Image library code you specified, the Camera type, and

Comp.Thickness value will be exported into the resourced component library record.

If you do not want to change any settings of the resourced component library record, click [No].

Note: If [Yes] is clicked, the three settings of Image code, Camera (Centering), and Comp.Thickness in

the resourced component library will be modified according to the edited image library. If

there is at least one setting of them that should not to be modified, select [No] here, and later

you should change only the necessary setting of the component library manually.

Chapter 5 Libraries

5-39

5-1-3-3 Component Library (Component Data)

Menu: Program>ComponentData

Program>PickupData>ComponentCode>ComponentData

Note: Edit>View(Simple) only shows [Component code], [Comment], [Image Code], [Centering],

[Nozzle No.], [Polarity] and [Thickness].

Window:

File>Save: Overwrites the currently saved data. The saved data can be utilized

for programming.

Edit: Menus pulled down from the Edit menu are used in the same way

as the menus of the program editor. See Chapter 2.

Library: Access the image library or nozzle library.

Component Code: Serves to link the component library and program editor.

* Up to 38 characters can be entered.

Comment: Any appropriate comment

* Up to 40 characters can be entered.

Image Code: Serves to link the component library and image library. To use a

pre-registered image code, click the right mouse button to list the

codes and select from them.

* Up to 38 characters can be entered.

Component Image Data

When the same component is set on both ST-F and ST-R, the same component

image code can be used in common. This image data must be created based on

the component image when picked up from ST-F. This is also true even when

the component is set only on ST-R.

Delay Vacuum On: Specify whether to use the Delay Vacuum On function (Use/Not

Use). This function allows the head to stop vacuuming during the

head down for pickup and restart when the head is completely

lowered. This prevents a component to be picked up while the head

is still moving down. Using this function may increase cycle time,

though.

Centering: Specify the camera to process the component. Click the right mouse

button to list available cameras and select one. （Varies with

installed options）

Fixed Camera1

Fixed Camera2

Scan Camera

Beam Camera

The camera specified here is used for the job run. (the camera

specified for the image library editor is not used.)

Note: For M7, select the beam camera.

Nozzle No.: Serves to link the component library and nozzle library. Click the

right mouse button to present the spin box for specifying the nozzle

number

Coplanarity: Specify whether to check the coplanarity of the component

(optional). To enable this function, the following two items should

be selected.

a. [Coplanarity Check] in User Parameter

b. [Coplanarity Check] in SystemParameter>MachineConfig.1
