7-6 User's Guide For Tape Fe eder Calibration Jig
7-5
Service Part List
Memo
Nos. 1~31 parts do not include fastening parts. They can be purchased
individually.
Nos. 70~84 parts are fastening parts. Fastening parts can be
purchased only as part of a package. The fastening parts included in
the package are those required to assemble one set of calibration jig
and master feeder.
wPackage Material No.: AM03-022317A
83 FC18-901877 SOCKET HEAD CAP SCREW 2 M5L50
84 FC18-901878 SOCKET HEAD CAP SCREW 2 M5L60
NO. PART NO. PART NAME Q'TY REMARK
7-6
User's Guide For Tape Feeder Calibration Jig
7-7
Service Part List
Memo
No. 85 part is a fastening part. Fastening parts can be purchased only
as part of a package. The fastening parts included in the package are
those required to assemble one set of calibration jig and master
feeder.
wPackage Material No.: AM03-022317A
NO. PART NO. PART NAME Q'TY
REMARK
32 GD03-000023A INSTALL GUIDE 1
33 AM03-012040A SME MASTER TOOGLE ASSY 1
34 J70653935A T LINK1 HINGE 2
35 J7066040A TOGGLE SPRING 1
36 J70661204A LOCKER-SPG-SHAFT 1
85 FC18-901932 FLAT HEAD CAP SCREW 3 M3X12
