6-4 User's Guide For Tape Fe eder Calibration Jig The siz e of the master tape origin is different fr om th a t o f the re cog niti on line when grabbing it. The vision resolution value is not appropriate. Adjust th…
6-3
TroubleShooting
When
rerunning
the
calibration
jig program
after it was
shut down,
camera
and CAN
communic
ation
failure
occurred.
USB device conflict occurred. Remove the USB from the PC
and rerun the calibration jig
program.
The
calibration
jig program
execution
screen is
cut.
The display resolution is less than
1920x1080.
Set the display resolution to
1920x1080 and higher.
The origin
of the
master
feeder is
not shown.
The master feeder is not clamped. Move the master feeder lever
up and clamp it.
The XY positions are not correct. Adjust the stage XY axes so
that the origin of the master
feeder can be seen.
A clearance occurred between
master feeder and feeder base.
Remove the foreign materials
from the feeder base.
The origin
of the
master
feeder
looks
blurred.
The master feeder is not clamped. Move the master feeder lever
up and clamp it.
The Z position is not correct. Adjust the stage Z-axis.
A clearance occurred between
master feeder and feeder base.
Remove the foreign materials
from the feeder base.
When
setting the
origin of
the master
feeder, its
position is
not correct.
The threshold value is not
appropriate.
Adjust the threshold value so
that the feeder origin can be
seen clearly.
Problem Possible Cause Measures
6-4
User's Guide For Tape Feeder Calibration Jig
The size of
the master
tape origin
is different
from that of
the
recognition
line when
grabbing it.
The vision resolution value is not
appropriate.
Adjust the resolution value and
perform setup so that the origin
size will be the same as the
recognition line size.
When
inputting a
serial
number
through
barcode
scanning, it
is different
from the
saved
value.
When inputting a serial number, an
incorrect value was inputted
manually.
Have the barcode recognized
using the barcode scanner.
Failed to recognize the serial
number properly due to a
communication defect.
Refer to the problem,
[Communication not available].
After replacing the main board, the
serial number is not saved in the
main board.
Save the serial number in the
main board in the Repair
menu.
When
inspecting
the part
supply
accuracy,
back-
feeding is
not
performed.
The firmware version of the tape
feeder is 1.26 and below.
Update the firmware version of
the tape feeder to version 1.26
and above.
When
inspecting
the part
supply
accuracy,
the <X
NG>
occurred.
Foreign material is jammed in the
feeder base slot when setting the
origin of the master feeder.
After removing the foreign
material, set the origin again.
The master feeder is not clamped
when setting the origin.
Clamp the master feeder and
set the origin.
The tape feeder is bent. Adjust the X eccentric pin and
inspect the supply accuracy
again.
The X position was set incorrectly
while performing mapping.
Adjust the X eccentric pin and
inspect the supply accuracy
again.
Problem Possible Cause Measures
6-5
TroubleShooting
When
inspecting
the part
supply
accuracy, a
<Y NG>
occurred.
The threshold value is too small or
too large.
Set the master tape threshold.
Lots of adhesive foreign materials
exist on the master tape.
Replace the master tape.
The master tape is damaged. Replace the master tape.
The start position of the master
tape inserted in the tape feeder is
incorrect.
Initialize the start position of
the master tape.
The intensity of the coaxial lighting
is insufficient.
Set the coaxial lighting for the
calibration jig.
The intensity of the fiducial lighting
is insufficient.
Set the fiducial lighting for the
calibration jig.
The sensor has not been initialized. Initialize the sensor and
perform mapping.
Mapping has not been finished. Initialize the sensor and
perform mapping.
The mapping data has been lost. Input the serial number and
initialize the sensor. Then
perform mapping.
Foreign material is jammed in the
feeder base slot when setting the
origin of the master feeder.
Remove any foreign materials
and set the origin.
The feeder is not clamped when
setting the origin of the master
feeder.
Clamp the master feeder and
set the origin.
The Y position was set incorrectly
while performing mapping.
Initialize the sensor and
perform mapping.
