4-17
Program Installation
Caution
Turning off the power supply to the tape feeder while
upgrading the tape feeder firmware will cause serious
damage to the tape feeder main board.
Do not turn off the power supply to the tape feeder while
upgrading the firmware. Otherwise, we are not responsible
for the damage to the main board considering that the main
board was damaged due to user's carelessness.
When a problem occurs, contact our C/S.
5-1
Maintenance
Chapter5. Maintenance
5.1. Calibration Jig Maintenance and Maintenance Items
Table5.1 Periodical Inspection
Table5.2 Consumables Replacement Cycle
Item Description
Inspection
interval
Calibration Jig Remove of foreign materials on the feeder base
/ vertical plate.
Daily
Apply rust preventive oil to the feeder base /
vertical plate
6 months
Tape Feeder Inspect tape feeders Annually
Lifetime management and overhaul Feeding
count: 40
million
Master Feeder Check the origin of the master feeder. Annually
Item Replacement Cycle
Master Tape After using 150 times (Refer to "5.5. Master Tape Usage
Management")
Feeder Base
Board
After installing/removing feeders in/from the feeder base slots
10,000 times (Refer to "5.6. Feeder Base Board
Replacement")
