第一章系统描述

1.2.3

光学系统（

Fiduciallymark

光学对准标记）

Optical system(Fiduciallymark optical

alignment mark)

标记点探测

Fiducial Mark Detection

用一个 CCD 相机通过网板和基板上两个标志点进行识别

Use a CCD camera to detect through the two fiducial marks

on the stencil and base board

调整方式

Alignment Mode

用相机探测到 PCB 和网板位置，通过视觉校正系统软件控制

万向工作台作 X—Y—θ方向修正，实现网板与基板的对准

Use camera to detect the position of PCB and stencil.

Correct the X—Y—θdirection of the worktable through the

visual alignment system software and insure the alignment

of the stencil and base board.

标记点形状

Fiducial Mark Shape

任何形状

Any shape

标记点大小

Fiducial Mark Size

可做成直径或边长为 1mm～2.5mm 的各种形状的孔，允许偏

差10%

Any shape of holes which diameter or length are 1mm ～

2.5mm. 10% offset allowed.

标记点类型

Fiducial Mark Type

透空型：周边用薄铜材料

半透空型：中间为透明或半透明涂层材料可用镍、青铜等

Open type: thin copper material on the surrounding.

Half-open type: transparent or semitransparent coating

material on the middle. Can be nickel, bronze, etc.

标记点要求

Fiducial Mark Require

标志点涂层表面要求平且光滑

Coating surface of the fiducial mark need be even and

smooth.

- 15

1.3

机器外形尺寸 Equipment dimension

注：机器外形尺寸认具体机型为准

notes：The external dimensions of the machine are subject to the specific model

图 1-1 机器外形图 Pix 1-1 Equipment dimension

1.4

系统的主要组成 Main sections of the system

本机包括机械、电气两大部分。

机械部分由平台校正系统、

PCB

传输及其定位系统、图象捕捉系统、钢网自动定位及其

清洁系统、刮锡系统等组成。电气部分由电控系统及控制软件、计数器、驱动器、步进电机、

伺服电机以信号监测、和气动系统系统组成。

The equipment includes two sections, machinery and electric.

Mechanical section includes table alignment system, PCB transmission and its

positioning system, image capture system, stencil automatic positioning system and

corresponding cleaning system and solder paste removed system,etc. Electrical section

includes electronic control system and control software, counter drive, stepping motor, servo

motor, signal monitoring system and pneumatic system.
