2.7
软件安装 Software installation
2.7.1 软件功能简介 Software introduction
本软件是自动化设备有限公司最新推出的 全自动视觉印刷机控制软件，具有 Windows7
视窗操作界面，功能强大，参数设定方便，操作简单且安全可靠，易学、易用。
This automatic visual printing control software is researched by our company.
Windows7 interface powerful functions and safe. Easy to set parameter, learn and operate.
此软件在全自动视觉印刷机上的应用，实现了机电一体化的控制，大大地提高了印
刷机的自动化程度和控制精度，保证了印刷质量。
This software applied on the automatic visual printer realizes the control of mechanical
and electrical integration. It improves the automatic level and control accuracy of the printer
and insures the printing quality.
本机器所用软件具有如下一些功能：
This equipment software owns following function:
1) 印刷参数设定
Printing parameter setting
2) 机器参数设定
Equipment parameter setting
3)
导轨宽度自动调节
Adjust the width of rail automatically
4) 视觉系统辨识及钢网与 PCB 板自动对准
Visual system identification, alignment of the stencil and PCB board
5)
网板与
PCB
板自动夹紧
Stencil and PCB board can clamp automatically
- 33
6)
网板自动清洗
Automatic cleaning of the stencil
7) I/O 故障自动检测并声光报警、提示故障原因
Automatic inspect the I/O fault and sound-light alarm and indicate the reason of the
fault
8) 报警记录
Alarm record
9)
生产设置
Production setting
10) 自动归零操作
Return to zero automatically
11) 在线 PCB 板计数
Online PCB board counting
12) 自动钢网定位
Automatic positioning of the stencil
13)
自动刮刀测高
Automatically measure the height of the scraper
2.7.2 软件安装 Software installation
机器出厂前已经安装了驱动软件和操作系统软件。在使用过程中，如须重新安装，请按
下列步骤进行。
The equipment has installed the driving software and operating system software. If
the software need be reinstalled during the operation, please do it according to the
following steps.
1) 打开电脑 F 盘。Open the Disk F in the computer.
2)把 HTGD 文件复制到电脑 C 盘的根目录下。
Copy the HTGD files to the root
directory of the Disk C.
3)
打开 HTGD 文件， Open the HTGD files.
4)
完成后把
“ ”
图标用快捷方式放到桌面上。Put the
“ ”
icon on
the
desktop with shortcut.
5)
在桌面上双击
“
”图标即可打开驱动软件。
Open the driving software
by double clicking the “ ”icon
- 34
-
第三章 生产工作流程
Chapter 3 Production flow
3.1
开机前检查 Check before turning on the equipment
检查所输入电源的电压、气源的气压是否符合要求；
Checking all the input voltage of the power and pressure of the air power meets
the requirements.
检查机器各接线是否连接好；
Check whether all lines are connected.
检查设备是否良好接地；
Check whether the equipment is grounded.
检查气动系统是否漏气，空气输入口过滤装置有无积水，是否正常工作。
Check whether pneumatic system leaks and whether there is water in the air input
port filter and normally work.
检查机器各传送皮带松紧是否适宜；
Check whether the transmission belt is loose.
检查是否有无关的碎物留在电控箱内，电控箱内各接线插座是否插接良好；
Check whether there is residue inside the electric control case and whether all the
sockets are connected.
检查有无工具等物遗留在机器内部；
Check whether there is any tool lost inside the equipment.
根据所要印刷的 PCB 板要求，准备好相应的网板和锡膏；
Prepare the stencil and solder paste according to the requirements of the PCB
board printing.
检查磁性顶针是否按所要生产的 PCB 尺寸大小摆放到工作台板上;
Check whether the magnetic thimble is put on the worktable according to size of
PCB board.
检查清洗用卷纸有无装好，检查酒精箱的液位（液面应超出液位感应器）；
Check whether the rolled paper is installed and the liquid level inside the alcohol
tank (Liquid level should be beyond the liquid level sensor).
