注：Notice:
A．
[
钢网夹紧阀
]
：侧夹钢网；
(ClampSwitch): Side clip steel mesh
B．
[
钢网装载
]
：把钢网拖到Y向位置
(Stencil AutoLoad):Dray the steel mesh to the
Yposition
C
．
[
清空标志点
]
：把所有Mark点坐标全部清除；
(delete all mark): Clear the coordinates of all mark points.
C
．
[
增加防呆点
]
：防止板放反增加一个标志点
(PolarizingMark): Add a mark point to prevent
the board from being reversed
E
．
[
宽度调节
]
：对进行运输导轨宽度调节；
(width adjustment): To adjust the width of transmission rail.
F．[移动挡板气缸]：将 CCD 移动到设置的坐标上去；
(remove damper cylinder): Remove CCD to the setup position
G．[网框固定阀]：自动定位钢网的时候，点击该按钮机器会松开钢网支撑架，用手将钢网
架移到指定位置，并夹紧；
(frame fixed valve):Clicking this button when do the stencil’s automatic positioning,
the equipment will loose the support frame and remove the stencil supporting frame
to the designated spot and fix it by hand.
H．[钢网定位]：自动定位钢网的时候，钢网自动气缸会随刮刀横梁移动到指定的位置，并
伸出气缸杆，将钢网插到气缸杆位置后点击[确定]，系统重新将钢网锁紧；
(stencil positioning): When do the stencil’ automatic positioning, the stencil automatic
cylinder will move to the designated spot along with scraper beam and will release
cylinder guide. Plug the stencil into cylinder guide and click “确定 ”（ok）button, the
system will re-fasten the stencil.
I． [钢网微调]：当钢网定位位置不准确时，可点击此按钮并用鼠标调整挡钢网气缸位置。
(stencil fine adjustment ): When the positioning of the stencil is not correct, click this
button and adjust the position of stencil cylinder with mouse.
J．[刮刀后退]：让刮刀后退到后起点位置，手工对钢网的时候使用；
(scraper back ): Let scraper comes back to the starting position at the back. Do it
when operate manually on the stencil.
K．[Z 轴上升]：Z 轴上升到印刷位置。手工对钢网的时候使用，看焊盘和网孔是否对正；
(Z axis lifts up): Z axis lifts up to the printing position. Do it when operate manually on
- 47
-
the stencil. Check whether the bonding pad align at the hole.
L．[CCD 回位]：点击后 CCD 会回到原点，手工对钢网的时候使用。
(CCD return): Click it and CCD will return to the original spot. D Do it when operate
manually on the stencil.
M．[MARK 点设置]：点击后 PCB 标志点成可编辑状态。
(MARK setting): Click it and PCB mark will become editable.
N
．
[Z
轴到取像位置
]
：点击后
Z
轴会升到取像位置，手工对钢网的时候使用；
(Z axis comes to the position of capturing image): Click it and Z axis will lift to the
position of capturing image. Do it when operate manually on the stencil.
O．[自动定位]：点击后机器会自动定位 PCB。这个按钮经常使用，通常设置好 PCB Mark
点到边的距离后点击该按钮，机器会自动执行停板气缸到位、
PCB
压板机构开启、
PCB
传送、PCB 到位停止、Z 上升到取像位置、侧压夹紧、PCB 压板机构关闭、停板气缸
复位、CCD 回到原点。至此 PCB 定位完毕，后面只需进行 PCB，钢网 Mark 点匹配
即可。
(automatic positioning):Click it and the equipment will automatically positioning the
PCB. This button will be used frequently. Click this button after setting the distance
between the PCB Mark and the side. The equipment will automatically execute the
return and reset of board limit cylinder, the open and close of the PCB pressure
plate mechanism, PCB transmission, the stop at given spot of the PCB. And the Z
axis will lift up to the position of capturing image and lateral pressure will clamp.
Then PCB positioning has been done. Next should need be done is to match the
PCB and stencil mark spot.
a．(挡板气缸)：开启/关闭停板气缸；
( board limit cylinder):Turn on /turn off board limit cylinder
b．(运输开关)：开启/关闭运输传送带；
(transmission switch): Turn on /turn off transmission belt
c
．
(
压板到位
)
：开启
/
关闭导轨压板；
(pressing plate in place): Turn on /turn off the pressing plate of the rail
d．(平台顶板)：平台顶起 PCB 上升到取像位置；
(platform lifts the board): Platform lifts the PCB to the position of capturing image.
e．(平台松板)：平台从取像位置下降到进板高度（Z 轴回到原点）；
(platform declines the board): Platform declines to the boarding height(Z axis return to
