8 SQUEEGEE MODULE 8.2 ELECTRICAL SCHEMATIC 130 TECHNICAL REFERENCE MANUAL DEK TQ 04/2021 Machine Controller Controller Power Module (C P M) Fibre Optic Links S IO Link Cables Drip T ray Cylinder In 4S E13 Drip T ray Cyli…
8 SQUEEGEE MODULE
8.2 ELECTRICAL SCHEMATIC
TECHNICAL REFERENCE MANUAL DEK TQ 04/2021 129
8.2 ELECTRICAL SCHEMATIC
M
M
Front
Squeegee
MTR28
Rear
Squeegee
MTR29
Extended Power Module
EPM2-1
Extended Power Module
EPM2-2
Machine Controller
Controller Power Module
(CPM)
J4 EPM2PL15EPM2PL13
Fibre
Optic
Links
Ribbon Cables
SIO Link
Cables
EPM2PL16EPM2PL14
4SK10
4SK11
J4
ESIO-4
ESIO-5
ESIO-3
ESIO-3: Breakout A
ADC/DAC
Board 5
Conditioning Board
IO1
IO2
IO4 IO5
3ASK2
M73PL5
5PL3
M73SK1
Front
Squeegee
4SE8
Rear
Squeegee
4SE9
Home
Sensor
Home
Sensor
3ASK23
3ASK24
3ASK13
3ASK14
Squeegee
Load Cell
5SE1
M73PL4
M73PL2
Connector for break-off
temperature and humidity board
5PL6
°C
%RH
8 SQUEEGEE MODULE
8.2 ELECTRICAL SCHEMATIC
130 TECHNICAL REFERENCE MANUAL DEK TQ 04/2021
Machine Controller
Controller Power Module
(CPM)
Fibre Optic Links
SIO
Link
Cables
Drip Tray
Cylinder In
4SE13
Drip Tray
Cylinder Out
4SE14
ESIO-4
ESIO-5
IO3
IO4
4PL22
4PL23
Sensor
Sensor
Drip Tray
5SOL5
IO2
Squeegee Drip Tray
Machine Controller
Controller Power Module
(CPM)
Fibre Optic Links
SIO Link
Cable
ESIO-5
Paste Roll
Height Monitor
5SE5
5PL85PL2
ADC/DAC
Board 5
ADC/
DAC
IO4
Paste Roll Height Monitor
8 SQUEEGEE MODULE
8.3 ADJUSTMENTS AND SETTINGS
TECHNICAL REFERENCE MANUAL DEK TQ 04/2021 131
8.3 ADJUSTMENTS AND SETTINGS
8.3.1 PRHM Sensor
CAUTION
RADIATION. RISK OF INJURY TO THE EYES DUE TO LASER LIGHT BEING
PRESENT IN THE VICINITY OF THE LABEL. DO NOT LOOK AT THE LIGHT
SOURCE OR REFLECTIONS FROM A SURFACE.
CAUTION
EQUIPMENT SERVICING. THE LASER DOES NOT CONTAIN USER
SERVICEABLE PARTS. OPENING THE UNIT COULD CAUSE MIS-ALIGNMENT
OF THE LASER, THIS MAY MAKE THE EQUIPMENT DANGEROUS TO
OPERATE.
CAUTION
LASER CONTROLS AND ADJUSTMENTS. USE OF CONTROLS OR
ADJUSTMENTS OR PERFORMANCE OF PROCEDURES OTHER THAN THOSE
SPECIFIED HEREIN MAY RESULT IN HAZARDOUS RADIATION EXPOSURE.
To reset the paste roll height monitor laser sensor to its factory default setting, carry out the follow-
ing procedure:
1. Select Menu.
2. Select Service\Diagnostics.
3. Select Confirm.
4. Select Print Carriage.
5. Select Carriage To Front.
6. Press the E Stop button.
7. Open the front cover.
