TRANSPORTATION
MACHINE POWER UP SEQUENCE
34.106 Technical Reference Manual Chapter Issue 7 Oct 06
E Stop Loop
Operation
17. Carry out the following:
a. Restart the DEK program.
b. During the machine initialisation, press the System button when
prompted.
c. On completion of the machine initialisation, check correct operation of the
E Stop Button and printhead cover/shutter.
d. If the E Stop button is activated, ‘System Power Down’ is displayed on
the monitor. If the printhead cover/shutter is opened, ‘Cover Opened’ is
displayed on the monitor.
e. After rectifying the E Stop condition, press the System button when
prompted.
Screen Cleaner Function Check
WARNING
RECOMMENDED SOLVENTS. ANY SOLVENTS USED MUST COMPLY WITH
LOCAL ENVIRONMENTAL GUIDELINES. DEK RECOMMEND USING SOLVENTS
THAT ARE ENVIRONMENTALLLY FRIENDLY, IE CFC FREE AND WATER BASED.
SOLVENTS USED MUST HAVE FAST EVAPORATION RATES AND FLASHPOINT
SPECIFICATIONS GREATER THAN 39ºC.
WARNING
SOLVENT SPRAY. THE UNDERSCREEN CLEANER SPRAYS A FINE JET OF
SOLVENT SOLUTION ON TO THE CLEANER. APPROVED PROTECTIVE
CLOTHING SHOULD BE WORN.
WARNING
SOLDER PASTE AND SOLVENTS. WHEN USING OR HANDLING ANY SOLDER
PASTE OR SOLVENT FORMULATION THE MANUFACTURERS’ RECOMMENDED
SAFETY PRECAUTIONS MUST BE STRICTLY ADHERED TO.
WARNING
PROTECTIVE CLOTHING. APPROVED PROTECTIVE CLOTHING SHOULD BE
WORN BY SOLDER PASTE AND SOLVENT HANDLERS AT ALL TIMES TO
ELIMINATE FUME INHALATION, EYE CONTACT, SKIN CONTACT AND
INGESTION.
Blue/Cyclone USC To setup the blue/Cyclone under screen cleaner carry out the following:
1. Ensure that the external solvent tank is fitted with an empty 5 litre container.
2. From the Start menu, select Show Classic.
3. Select Maint..
4. Select Calib Machine.
5. Select Solvent.
6. Select Set Solv Empty and confirm by selecting Yes.
7. Replace the empty 5 litre container with a 5 litre container full of the solvent
to be used.
8. Select Set Solv Full and confirm by selecting Yes.
9. Select Exit.
10. Select Exit.
TRANSPORTATION
MACHINE POWER UP SEQUENCE
Chapter Issue 7 Oct 06 Technical Reference Manual 34.107
11. Select Exit.
12. Select Open Cover and lift the front printhead cover/shutter.
13. Select Prime Solvent and when prompted press the two button control
switches simultaneously until the paper is wet (this may take several
attempts before solvent is sprayed onto the paper).
14. Select Prime Paper and when prompted press the two button control
switches simultaneously to feed a clean area of dry paper over the solvent
dispense pipe ensuring that the paper feeds correctly.
15. Select Exit.
16. Select Hide Classic to return to the main screen.
17. Close the front printhead cover/shutter and press the System button.
Vortex USC To setup the Vortex under screen cleaner carry out the following:
1. Ensure that the external solvent tank is fitted with an empty 5 litre container.
2. From the Start menu, select Show Classic.
3. Select Maint..
4. Select Calib Machine.
5. Select Solvent.
6. Select Set Solv Empty and confirm by selecting Yes.
7. Replace the empty 5 litre container with a 5 litre container full of the solvent
to be used.
8. Select Set Solv Full and confirm by selecting Yes.
9. Select Exit.
10. Select Exit.
11. Select Exit.
12. Select Open Cover and lift the front printhead cover/shutter.
13. Select Prime Solvent and when prompted press the two button control
switches simultaneously until the cleaning cassette wet cell is impregnated
with solvent (this may take several attempts before solvent is sprayed onto
the wet cell).
14. Select Exit.
15. Select Hide Classic to return to the main screen.
16. Close the front printhead cover/shutter and press the System button.
TRANSPORTATION
MACHINE POWER UP SEQUENCE
34.108 Technical Reference Manual Chapter Issue 7 Oct 06
ProFlow Contact
Position setup
For machines using ProFlow only, set up the contact height position as follows:
1. Load a stencil with an off centre image.
2. Fit an empty transfer head to the ProFlow pressure mechanism. Remove
the cover.
NOTE
Ensure wipers and skis are fitted to the transfer head.
CAUTION
MACHINE JAMMING.
In order to prevent the inadvertent jamming of squee-
gee mechanical mechanisms, the following procedure must be carried out
in the correct sequence.
3. Position a 0.1mm shim on the stencil under the transfer head.
4. Select Show Classic.
5. Select Maint..
6. Select Calib Machine.
7. Select ProFlow.
8. Select ProFlow Heights.
The following window and menu bar is displayed:
9. PFLOW CONTACT POS. is highlighted.
This parameter sets the height of the ProFlow printhead so that it just
touches the stencil surface.
Run
Open
Cover
Knead
Paste
Clean
Screen
Adjust Setup Monitor Maint.
Calib
Machine
House
Keeping
Set
Prefs
Diagnost
Te st
Cycles
Exit
ProFlow Offset Vision Solvent Exit
ProFlow
Heights
Transfer
Material
Exit
ProFlow Calibrations
PFLOW CONTACT POS.
0.0
mm
Move to
Position
Restore
Defaults
Next Previous Incr. Decr. Exit
Minimum Maximum Increment Default
- 10mm +10mm 0.1mm 0.0mm
