1 Operational Safety SIPLACE 80S-20/F4/F5 User Manual 1.1 Information on safety 05/99 Issue from Softwar e Version SR.405.xx 1 - 8 RISK OF TRAPPING HANDS IF PROT ECTIVE COVERS ARE CLOSED INCORRE CTL Y Item 4 in Fig. 1.1.…
SIPLACE 80S-20/F4/F5 User Manual 1 Operational Safety
05/99 Issue from Software Version SR.405.xx 1.1 Information on safety
1 - 7
Item 2 in Fig. 1.1.1 showing the warning signs on the basic machine
Item 3 in Fig. 1.1.1 showing the warning signs on the basic machine
1 Operational Safety SIPLACE 80S-20/F4/F5 User Manual
1.1 Information on safety 05/99 Issue from Software Version SR.405.xx
1 - 8
RISK OF TRAPPING HANDS
IF PROTECTIVE COVERS ARE CLOSED INCORRECTLY
Item 4 in Fig. 1.1.1 showing the warning signs on the basic machine
Item 5 in Fig. 1.1.1 showing the warning signs on the basic machine
Item 6 in Fig. 1.1.1 showing the warning signs on the basic machine
VORSICHT NETZSPANNUNG
Vor Abnehmen der Schutzabdeckung
Netz vollständig abschalten
Kondensatorentladezeit
tmin. = 0,25 Minuten abwarten
WARNING! MAIN POWER VOLTAGE!
Completely isolate the machine
before removing the protective cover.
Capacitor discharge time
tmin. = wait 0.3 minutes
SIPLACE 80S-20/F4/F5 User Manual 1 Operational Safety
05/99 Issue from Software Version SR.405.xx 1.1 Information on safety
1 - 9
Fig. 1.1.2 Warning signs on the basic machine - part 2
Key to Fig. 1.1.2
(1) Main switch
T PCB transport direction
Item 2 in Fig. 1.1.2 showing the warning signs on the basic machine
