PVA Portal Manual
Revision I / January 2022
Page 8 of 106
1.3 Safety
Certain warning symbols are affixed to the machine and correspond to notations in this
manual. Before operating the system, identify these warning labels and read the notices
described below. Not all labels may be used on any specific system.
Always wear approved safety glasses when operating or working near the
workcell.
Before operating the system, read and understand the manuals provided
with the unit.
Never put hands or tools in areas with this symbol when the machine is in
operation. A dangerous condition may exist.
Read and understand the manuals provided with the unit before any repairs
or maintenance is done. Only a qualified individual should do service.
Use caution when there are pressurized vessels. Find and repair any leaks
immediately. Always wear appropriate safety equipment when working with
pressurized vessels or vessels that contain chemicals
Shear hazard from moving parts. Avoid contact.
Do not remove protective guarding.
In situations where inattention could cause either personal injury or damage
to equipment, a warning notice is used.
PVA Portal Manual
Revision I / January 2022
Page 9 of 106
Do not smoke near the machine. Always have a fire extinguisher available
for emergency use.
Before performing any repairs or maintenance to the system, turn off power
and lock out the power disconnect switch.
Warning notices are used to emphasize that hazardous voltages, current,
temperatures, or other conditions that could cause personal injury exist in
this equipment or may be associated with its use. Only qualified personnel
should enter areas designated with this symbol.
Laser light source present. Do not stare directly into the beam. Do not use in
the presence of highly reflective surfaces
Pinch hazard from moving parts. Avoid contact.
Hot surface. Avoid contact.
Warning, Ultraviolet (UV) light hazard. Do not look directly at the UV light
source.
This product meets EU standards for health, safety, and environmental
protection.
Warning, no open flames.
Electrostatic sensitive device warning. Observe precautions for handling.
PVA Portal Manual
Revision I / January 2022
Page 10 of 106
1.4 System Description
The manual applies to the following Precision Valve & Automation, Inc. workcells:
PVA350™ PVA6000™
PVA650™ Delta 6
PVA2000™ Delta 8
PVA3000™ Flex Cell
The dispense path and active heads are controlled by a program stored in the motion
controller. The motion controller can save up to 30 programs at one time.
The operator controls the workcell with PVA Portal software. This includes machine setup,
manual operation, program selection, and automatic operation. Machine status and error
messages are shown in the program window and the light tower. The operator(s) must
have read this manual or have been trained and understand the operation of the machine.
Any uses that are not approved could result in dangerous conditions that the safety
features on the system cannot prevent.
1.5 Personal Protective Equipment
Workcell operation includes air pressure, electrical power, mechanical devices, and the use
of hazardous materials. Only qualified personnel can operate and service workcells.
Operators must use eye protection because material contents are under pressure. Always
wear gloves when handling materials and solvents. Refer to MSDS sheets on the material
that is used for other precautions.
