Legal Information
Legal Information
Copyright
Copyright © 2023 Shenzhen Inovance Technology Co., Ltd. All rights reserved.
This documentation is the exclusive property of Shenzhen Inovance Technology Co., Ltd.
No individual or entity may excerpt, reproduce, modify, translate, or distribute any
content herein without written consent from Inovance.
Legal action will be taken against infringement.
Trademarks
is a registered trademark of Shenzhen Inovance Technology Co., Ltd.
and its affiliates. All other trademarks or registered trademarks mentioned in this
documentation are the property of their respective owners. Unauthorized use of these
trademarks by third parties for any purpose without written authorization could violate
the rights of their owners.
Disclaimer of Liability
Due to continuous updates and improvements of products and technologies, the content
of this documentation may not fully match the actual products. In the event of any
discrepancies, the actual products shall prevail.
The contents are subject to change without notice due to product upgrade.
Waste Disposal
The storage, use, and disposal of this product (including optional accessories) must
comply with local laws and regulations.
Qualified Personnel
The product/system described in this documentation may be operated only by personnel
qualified for the specific task in accordance with the relevant documentation, in
particular its warning notices and safety instructions. Qualified personnel can identify the
risks of the product/system and prevent possible dangers.
Proper Use of the Product
Proper transportation, storage, assembly, installation, commissioning, operation, and
maintenance are required to ensure the safe operation of the product without any
problems. The required ambient conditions must be met. All operations must follow the
guidelines provided in this documentation.
‑2‑
Preface
Preface
Introduction
The MD600 is a compact, general-purpose, and cost-effective AC drive for small
automation equipment. Supporting Modbus RTU and CAN communication protocols, it
features a compact size and high-performance open-loop vector control and can drive
synchronous and asynchronous motors. The MD600 is widely used in small automation
equipment in fields such as silicon, lithium, woodworking, logistics, cables, packaging,
and machine tools.
This guide describes product selection, mechanical design, electrical design, common
EMC problems and solutions, and product certifications and standards.
More documents
No. Name
Data code
Description
①
MD600 Series
Compact AC Drive
Quick Start Guide
19012337
This guide describes the installation and
operation, common faults and
troubleshooting, and parameter settings of
the drive.
②
MD600 Series
Compact AC Drive
Hardware Guide
(this guide)
19012234
This guide describes product selection,
mechanical design, electrical design,
common EMC problems and solutions, and
product certifications and standards.
③
MD600 Series
Compact AC Drive
Function Guide
19012238
This guide describes the basic function
configuration, function application,
communication configuration,
troubleshooting, and parameters of the
drive.
④
MD600 Series
Compact AC Drive
User Guide
PS00012434
This guide describes product selection,
mechanical design, electrical design, quick
installation and operation, function
application, communication configuration,
troubleshooting, common EMC problems and
solutions, and product certifications and
standards.
