Electrical Design
‑38‑
Table 4–6 Clearance for device installation at different layers (single-phase 200 V to 240
V)
Power Rating (kW) Clearance (mm)
0.37 A1 ≥ 20 B1 ≥ 100 C1 ≥ 80 D1 ≥ 30 E1 ≥ 80
0.75 A1 ≥ 20 B1 ≥ 100 C1 ≥ 80 D1 ≥ 0 E1 ≥ 80
1.5 A1 ≥ 20 B1 ≥ 100 C1 ≥ 80 D1 ≥ 0 E1 ≥ 80
2.2 A1 ≥ 20 B1 ≥ 120 C1 ≥ 80 D1 ≥ 0 E1 ≥ 80
Table 4–7 Clearance for device installation at different layers (three-phase 380 V to 480 V)
Power Rating (kW) Clearance (mm)
0.37 A1 ≥ 20 B1 ≥ 100 C1 ≥ 80 D1 ≥ 30 E1 ≥ 80
0.75 A1 ≥ 20 B1 ≥ 100 C1 ≥ 80 D1 ≥ 30 E1 ≥ 80
1.5 A1 ≥ 20 B1 ≥ 100 C1 ≥ 80 D1 ≥ 0 E1 ≥ 80
2.2 A1 ≥ 20 B1 ≥ 100 C1 ≥ 80 D1 ≥ 0 E1 ≥ 80
4 A1 ≥ 20 B1 ≥ 120 C1 ≥ 80 D1 ≥ 0 E1 ≥ 80
5.5 A1 ≥ 20 B1 ≥ 120 C1 ≥ 80 D1 ≥ 0 E1 ≥ 80
4.5.2 Heat Dissipation Design
4.5.2.1 Ventilation Requirements
Common heat dissipation methods include the following:
● Natural ventilation
● Forced air cooling
4.5.2.1.1 Air Duct Design
Heat dissipation design of the cabinet door
The cabinet is forcibly cooled by a built-in fan. Therefore, to ensure that enough cooling
air enters the cabinet, open an air inlet with an appropriate size on the cabinet door. For
details on the effective area of the air inlet, see
"4.5.2.1.2 Air Outlet and Inlet
"
on page 39
.
The air flows from bottom to top after being heated. Therefore, the cabinet air inlet must
be at least 50 mm lower than the air inlet of the drive, as shown below.
Electrical Design
‑39‑
Figure 4‑8 Position of the cabinet air inlet
4.5.2.1.2 Air Outlet and Inlet
Air inlet
The effective area of the air outlet is the actual ventilation area instead of the gross
opening area. The following table describes the minimum ventilation area of the cabinet
air inlet after the drive is installed in the cabinet.
Table 4–8 Minimum ventilation area of the cabinet air inlet (single-phase 200 V to 240 V)
Structure
Power (kW) Quantity
Min. Ventilation Area of Air
Inlet for Direct‑Ventilation
Cabinet (cm
2
)
T1
0.37 1 20.5
0.75 1 16.2
1.5 1 16.2
T2 2.2 1 22
Electrical Design
‑40‑
Table 4–9 Minimum ventilation area of the cabinet air inlet (three-phase 380 V to 480 V)
Structure
Power (kW) Quantity
Min. Ventilation Area of Air
Inlet for Direct‑Ventilation
Cabinet (cm
2
)
T1
0.37 1 20.5
0.75 1 20.5
1.5 1 16.2
2.2 1 16.2
T2
4 1 22
5.5 1 22
For example, on the plate shown in the following figure, the size of each hole is C x C,
and there are 9 holes. Therefore, the ventilation area of the air outlet is 9 x C x C.
The preceding tables apply only to a single product. For a cabinet containing multiple
products, calculate the total ventilation area by adding the ventilation area of each
product.
For example, a cabinet contains the following products:
T1 model (single-phase 0.37 kW) + T1 model (single-phase 1.5 kW) + T2 model (single-
phase 2.2 kW) + T1 model (three-phase 0.75 kW) + T1 model (three-phase 2.2 kW) + T2
model (three-phase 4 kW). Therefore, the minimum ventilation area of the cabinet air
inlet should be 20.5 + 16.2 + 22 + 20.5 + 16.2 + 22 = 117.4 cm
2
.
For air inlets installed with a filtering net, the air inlet resistance increases substantially.
In this case, the minimum ventilation area of the air inlet must be increased to 1.2 to 1.5
times the value listed in the preceding table. The ventilation area in the preceding tables
refers to the actual through-hole area of the opening. The ventilation area is calculated
by the following: opening area x opening rate.
Air outlet
To ensure sufficient heat dissipation of the drive, hot air in the cabinet must be exhausted
to the outside. Use the active ventilation design for the cabinet.
