Unpacking and Handling
‑83‑
9 Unpacking and Handling
Unpacking
1. Open the package of the AC drive (①).
2. Take out the cushion (②).
3. Take out the AC drive (③) and the accessory kit (④).
Figure 9‑1 Unpacking
Table 9–1 Unpacking list
No. Name
①
AC drive package
②
Cushion
③
AC drive
④
Accessory Kit
Storage
Store and transport the equipment as required to prevent damage.
● The drive must be stored in a clean and dry room, where the temperature ranges from
-20°C and +60°C and temperature change rate is smaller than 1°C/min.
● Do not store or transport the equipment in locations where the equipment may be
exposed to splashing water or rain, direct sunlight, strong electric field, strong
magnetic field, or strong vibration.
● Do not expose the drive to environments with moisture, high temperature, or strong
sunlight for a long time.
Unpacking and Handling
‑84‑
● If the drive needs to be stored for a long period of time, cover it or take other
appropriate measures to keep it from contamination and adverse environmental
impacts.
● Pack the drive with the original packing box provided by Inovance.
● Store the equipment for up to three months. Take stricter protective measures and
carry out the necessary inspections for a longer storage time.
● The electrolytic capacitor will deteriorate after long-term storage. Therefore, switch
on the drive once for at least 5 hours every 6 months. Increase the input voltage
slowly to the rated value by using a voltage regulator. Contact Inovance for technical
support if necessary.
● Pack the equipment securely and properly before transportation. Use a fully enclosed
container for long-distance transportation.
● Never transport the drive with other device or materials that may harm or have
negative impacts on the drive.
Handling
Note
● Large-scale or heavy equipment must be transported by qualified professionals
using specialized hoisting equipment. Failure to comply may result in personal
injuries or equipment damage.
● Before hoisting the equipment, ensure the components such as the front cover
and terminal block are secured firmly with screws. Loosely-connected
components may fall off and result in personal injuries or equipment damage.
● Never stand or stay below the equipment when the equipment is being hoisted
by the hoisting equipment.
● When hoisting the equipment with a steel rope, ensure the equipment is hoisted
at a constant speed without suffering from vibration or shock. Do not turn the
equipment over or let the equipment stay hanging in the air. Failure to comply
may result in personal injuries or equipment damage.
● When carrying the equipment with bare hands, hold the equipment casing firmly
with care to prevent parts from falling. Failure to comply may result in personal
injuries.
● Handle the equipment with care during transportation and mind your steps to
prevent personal injuries or equipment damage.
Maintenance and Repair
‑85‑
10 Maintenance and Repair
10.1 Routine Maintenance and Repair
10.1.1Routine checklist
The ambient temperature, humidity, dust, and vibration will cause aging of components
inside the drive, which leads to potential faults and shortens the service life of the drive.
Therefore, routine maintenance on the device is required. The maintenance interval must
be shortened when the drive is used in environments suffering from high ambient
temperature, frequent startup and stop, violent fluctuation in the AC power supply and
the load, strong vibration or shock, and intrusive and corrosive substances such as dust,
metal dust, and hydrochloric acid.
Check the following items daily to ensure a proper operation of the product. It is
recommended to make a copy of this checklist and sign the "Checked" column after each
inspection.
Item
Description Solution Result
Motor
No unusual vibration or
noise occurs during
operation of the motor.
● Ensure normal mechanical
connection.
● Check the motor for phase loss.
● Check whether motor screws are
tightened.
Cooling fan The cooling fans of the
drive and the motor
operate properly
without exception.
● Ensure the fan on the device side
operates normally.
● Ensure the fan on the device side
operates normally.
● Ensure that the air duct is not
clogged.
● Ensure that the ambient
temperature is within the
allowable range.
Installation
environ
ment
The control cabinet and
cable ducts are normal.
● Ensure the insulation of the
cables at the inlet and outlet is
not damaged.
● Ensure that the mounting bracket
does not vibrate.
● Ensure that the copper busbar
and cable terminals are
connected properly or are not
corroded.
