Requirements for Certification and Standards Compliance ‑ 130 ‑ 13 Requirements for Certification and Standards Compliance 13.1 Compliance List The following table lists the certifications, directives, and standards that…
Option
‑129‑
Table 12–23 Specifications and dimensions of the tube-type pre-insulated terminal (TG-JT)
Cross-sectional
area
Model Dimension (mm) Insulation
sheath color
(1) For Germany
(2) For France
Crimping tool
F L W DØ CØ
A.W.G.22
0.5 mm
2
E0510 10.0 16.0 2.7 1.3 1.0 (1) Orange
(2) White
OPT AN-04WF
A.W.G.20
0.75 mm
2
E7510 10.0 16.0 2.8 1.5 1.2 (1) White
(2) Blue
OPT AN-04WF
A.W.G.18
1.0 mm
2
E1010 10.0 16.5 2.9 1.7 1.4 (1) Yellow
(2) Red
OPT AN-04WF
A.W.G.16
1.5 mm
2
E1510 10.0 16.5 3.5 2.0 1.7 (1) Red
(2) Black
OPT AN-04WF
E1512 12.0 18.5 3.5 2.0 1.7 (1) Red
(2) Black
OPT AN-04WF
14AWG
2.5 mm
2
E2510 10.0 17.5 4.1 2.6 2.3 (1) Blue
(2) Gray
OPT AN-04WF
E2512 12.0 19.5 4.1 2.6 2.3 (1) Blue
(2) Gray
OPT AN-04WF
12AWG
4.0 mm
2
E4012 12.0 19.5 4.5 3.15 2.8 (1) Gray
(2) Orange
OPT AN-10WF
Requirements for Certification and Standards Compliance
‑130‑
13 Requirements for Certification and Standards
Compliance
13.1 Compliance List
The following table lists the certifications, directives, and standards that the product may
comply with. For details about the acquired certificates, see the certification marks on the
product nameplate.
Certification Directive Standard
CE
EMC Directive 2014/30/EU EN IEC 61800-3
LVD Directive 2014/35/EU
EN 61800-5-1
RoHS directive
2011/65/EU /
13.2 CE Certification
13.2.1Precautions for Compliance with EU Standards
Figure 13‑1 CE mark
● The "CE mark" indicates compliance with the Low Voltage Directive (LVD),
Electromagnetic Compatibility (EMC), and Restriction of Hazardous Substances (RoHS)
directives for commercial trades (production, import, and sales) in the EU.
● The CE mark is mandatory for engaging in commercial business (production,
importation, and distribution) in the EU.
● The drive complies with LVD, EMC, and RoHS directives and carries the CE mark.
● Machines and devices integrated with this drive must also comply with CE
requirements for distribution in EU.
● The integrator who integrates this drive into other products and attaches CE mark to
the final assembly has the responsibility of ensuring compliance with CE certification.
13.2.2Requirements for Compliance with EMC Directive
● This drive, which is applicable to the First environment and Second environment,
complies with EMC Directive 2014/30/EU and standard EN IEC 61800-3.
Requirements for Certification and Standards Compliance
‑131‑
If the product is used in the first environment, it may generate radio interference. In addi-
tion to CE compliance requirements, measures should be taken to prevent interference
when necessary.
● As required by EMC Directive and standard, install an EMC filter on the input side and
use shielded cables on the output side. Ensure the filter is grounded properly and the
shield of the output cable is grounded 360 degrees.
The manufacturer of the system with the product installed must ensure that the system
meets the requirements of the European EMC Directive, and ensure that the system meets
the requirements of the standard EN IEC 61800-3 according to the application environ-
ment of the system.
Introduction to EMC standards
Electromagnetic compatibility (EMC) describes the ability of electrical and electronic
devices or systems to work properly in the electromagnetic environment without
introducing electromagnetic interferences that disturb the operation of other local
devices or systems. Therefore, EMC includes the following requirements:
● The electromagnetic interference generated by the device or system during normal
operation must be within a certain limit.
● The device or system must have sufficient immunity to the electromagnetic
interference in the environment.
EN IEC 61800-3 defines the following two types of environments.
● First environment: Environment that includes domestic premises, and establishments
directly connected without intermediate transformers to a low-voltage power supply
network which supplies buildings used for domestic purposes
● Second environment: Environment that includes all establishments other than those
directly connected to a low-voltage power supply network which supplies buildings
used for domestic purposes
Devices are divided into the following four categories based on the intended
environment.
● Category C1: Power drive systems with the rated voltage less than 1000 V, intended
for use in the first environment.
