Requirements for Certification and Standards Compliance
‑132‑
● Category C2: Power drive systems with the rated voltage lower than 1000 V, which is
neither a plug-in device nor a movable device and is intended to be installed and
commissioned only by professionals when used in the first environment.
● Category C3: Power drive systems with the rated voltage lower than 1000 V, which is
intended for use in the second environment and not intended for use in the first
environment
● Category C4: Power drive systems with the rated voltage equal to or higher than 1000
V or rated current equal to or higher than 400 A, or intended for use in complex
systems in the second environment
13.2.3Requirements for Compliance with LVD
The product has been tested in accordance with EN61800-5-1 and complies with the Low
Voltage Directive. Observe the following requirements to enable machines and devices
integrated with this drive to comply with the LVD.
Installation location
Install the product in a place with overvoltage category III and pollution degree 1 or 2 as
specified by IEC 60664-1.
Installation Environment
For requirements of the installation environment, see
"5.1.1 Installation Environment
Requirements
"
on page 56
.
Installation protection requirements
● The drive serves as a part of a final system. Install the drive as the system component
in a fireproof cabinet that provides effective electrical and mechanical protection, and
install it in accordance with local laws and regulations and relevant IEC standards.
● For IP40-certified products, install them in structures where foreign objects cannot
enter from the top or front sides.
Wiring requirements for main circuit terminals
For details about the main circuit terminal wiring requirements, see
"6.2.2 Wiring
Description of Main Circuit Terminals
"
on page 65
.
Requirements for protective devices
To comply with EN 61800-5-1 standards, install a fuse/circuit breaker on the input side of
the drive to prevent accidents caused by short circuit in the internal circuit. Use a fuse that
matches the maximum input current of the AC drive. For selection of fuses, see
"12.3
Circuit Breaker and Fuse (CE)
"
on page 107
.
‑133‑
Service and Support
Service and Support
Should you encounter a safety accident during the use or operation of the product, or
face challenges in operating and maintaining the equipment, which remain unresolved
after the relevant documentation is consulted, we provide multiple channels to ensure
prompt resolution:
● Channel #1: Contact service@inovance.com.
● Channel #2: Visit https://www.inovance.com/global to access document downloads,
after-sales support, spare parts ordering, repair applications, and authenticity
verification services.
● Channel #3: Download My Inovance app (https://zshc-eu.inovance.com/download-
pc/) where you can access products info and documentation, and query product
parameters.
We are committed to providing you with quick and professional technical support, and
we look forward to your satisfaction and trust.
