3 Technical data and assemblies User manual SIPLACE SX1/SX2
3.5 Placement head From software version SC 706.1 SP1 Version 10/2014
116
3.5.4.4 Placement modes for MultiStar
The CPP head functions with different placement modes, which vary according to the component
class. The setup optimization selects the placement mode with the shortest cycle times. The fol-
lowing table shows the correlation between component class and placement mode.
Tab. 3.5 - 2 Relations between component class and placement modes
3.5.4.5 Assembly positions of MultiStar in the machine
Placement mode Component class
Small component Medium sized
component
Large component
Collect&Place mode Yes No No
Mixed mode Yes Yes No
Advanced
Pick&Place mode
Yes Yes Yes
Placement machine Assembly
position
*a
CPP head
Maximum component
height
Vision camera
SIPLACE SX1/SX2 Bottom 6.0 mm Head camera
Top 8.5 mm Head camera
Top only 11.5 mm
Stationary component
camera
Tab. 3.5 - 3Assembly positions of CPP head in the machine
*)a Please observe the rules for assembly position heights in section 3.5.4.2
, page 114.
User manual SIPLACE SX1/SX2 3 Technical data and assemblies
From software version SC 706.1 SP1 Version 10/2014 3.5 Placement head
117
3.5.4.6 MultiStar in Collect&Place mode
The MultiStar does not process components in this mode.
3
Fig. 3.5 - 6 MultiStar - Collect&Place mode
K_BE Small component (see table 3.5 - 1, page 115)
Type 30 Component camera, type 30
1 ... 12 Order of components taken up
3
Type 30
K_BE
3 Technical data and assemblies User manual SIPLACE SX1/SX2
3.5 Placement head From software version SC 706.1 SP1 Version 10/2014
118
3.5.4.7 MultiStar in mixed mode with complete rotation
The MultiStar processes small to medium sized components in this mode.
3
Fig. 3.5 - 7 MultiStar - mixed mode
K_BE Small component (see table 3.5 - 1, page 115)
M_BE_1 Medium sized component, type 1 (see table 3.5 - 1
, page 115)
M_BE_2 Medium sized component, type 2 (see table 3.5 - 1
, page 115)
Type 30 Component camera, type 30
Type 33 Stationary component camera, type 33
1 ... 8 Order of components taken up
1 ... 12 Order of components taken up
3
Neighboring segments of the CPP head are not able to take up components of type M_BE_2 if the
diagonal length of the medium sized component, type 2 (M_BE_2) is longer than 39.8 mm.
Type 30 Type 30
Type 33 Type 33
K_BE
M_BE_2
M_BE_1
K_BE
