5.11 Observing displays on the X feeder module From software version SC 706.1 SP1 Version 10/2014
274
5
5
Foil PeelErr
(Error while peel-
ing off the foil)
Red Foil was not peeled off even
though the tape is moved
The cover foil is probably jammed beneath
the pick-up window and cannot be peeled
off correctly
Foil Jam
(Foil jam)
Red Foil motor has locked up Leveling gears blocked by foil? => Remove
the foil
EEP-WriteErr
(Error while back-
ing up data in the
EEPROM)
Red The data back-up in the EE-
PROM was not carried out
correctly
Remove the component tape (tape can be
moved out by pressing the arrow keys or
pulled out after raising the pick-up window).
Press the SET button to confirm the error.
Then press the yellow button to confirm the
reference run prompt.
EEP-ReadErr
(Error while read-
ing
the EEPROM)
Red Data was not read from the
EEPROM correctly
EEP-DataErr
(Error while back-
ing up the data in
the EEPROM)
Red The data back-up in the EE-
PROM was not carried out
fully
Reference o
Reference o
Red Position information is no
longer available for the com-
ponent tape drive
Remove the component tape (tape can be
moved out by pressing the arrow keys or
pulled out after raising the pick-up window).
Then press the "FOIL" button to start the
reference run.
CAN BusError
(CAN bus error)
Red CAN bus error Log off and on again, check the optical fiber
interface
ParNotSaved! Red Parameters were not saved Default parameters are loaded automatical-
ly, i.e. the most recent operator settings are
overwritten -> The settings (e.g. increment)
will have to be made again. Replace the
control board if this error occurs frequently.
ParWrongSave Red Wrong or incomplete param-
eters were saved
BootFlashErr
FlashDataErr
Red Can no longer write to boot
or application memory cor-
rectly
Replace the feeder module or control board
PLEASE NOTE
Remove the component tape before a reference run.
Text on the
LCD display
Status
display
Meaning Solution

User manual SIPLACE SX1/SX2 5 Working with the machine
From software version SC 706.1 SP1 Version 10/2014 5.12 Changing the setup
275
5.12 Changing the setup
5.12.1 Printing out the conversion instructions before changing the setup
Before a change of setup, print out the conversion instructions on the printer for the SIPLACE Pro
computer as described in the "SIPLACE Pro" manual or in the online help.
5.12.2 What you should note when changing the feeder modules
Handle the feeder modules carefully when you insert them into or remove them from the
changeover table. Make sure that the X feeder modules do not bump against the centering
bar (see item 5 in fig. 5.10 - 3
, page 263) of the changeover table.
Vacuum the supporting surfaces of the feeder modules and clean the surface of the change-
over table when necessary according to the instructions in the preventive maintenance man-
ual.
5
Remove loose components using a brush or a vacuum cleaner with a suitable nozzle.
5
CAUTION
Risk of injuries!
Fine metal splinters from components could injure hands.
Avoid removing components from the changeover table with your fingers.

5 Working with the machine User manual SIPLACE SX1/SX2
5.13 Avoiding track errors From software version SC 706.1 SP1 Version 10/2014
276
5.13 Avoiding track errors
5.13.1 General
Make sure that the areas around the feeder modules are clean and that there are no loose
components in the feeder area or under the feeder modules.
Refill promptly with components.
Splice the tapes early. This generally means that you are to prepare the splicing material
when there is still approximately 1.5 m of tape on the reel.
Handle the feeder modules carefully when you insert them into or remove them from the
changeover table as these are high-precision devices.
For X feeder modules, lower the pickup window since it can easily be damaged when raised.
5
Check that the pick-up position is set correctly for the components on the feeder modules.
5.13.2 Avoiding track errors with the tape container
Insert the separating plates correctly (see fig. 5.9 - 3, page 258).
PLEASE NOTE
A raised pick-up window leads to noticeably impaired pick-up quality.
