6.3.3 Technical data
6
6.3.4 Dimensions with JTF-M/JTF-S
6
Fig. 6.3 - 2 Dimensions of SX machine with JTF-M/JTF-S
SIPLACE JTF-S SIPLACE JTF-M
Width
162 mm 177 mm
Height
587 mm 587 mm
JEDEC waffle pack tray specification JEDEC Standard: 95-1 & IEC 60286-5
Storage capacity
Waffle pack tray, thin 30 JEDEC waffle pack trays 18 JEDEC waffle pack trays
Waffle pack tray, thick 20 JEDEC waffle pack trays 14 JEDEC waffle pack trays
Waffle pack tray changeover time
< 5 seconds (depending on
application)
--
Slot n to n+1 -- 3.5 seconds
Slot 1 to 18 -- 10 seconds
Slot 18 to 1 -- 8.9 seconds
Cassette
--
Dimensions -- approx. 330 mm x 150 mm x 230 mm
Max. load capacity -- 2.7 kg (150 g each for 18 slots)
Pneumatics
4.1 bar to 5.5 bar 5.2 bar to 9 bar
Compressed air consumption
< 28.3 NL/min. < 28.3 NL/min.
6 Station extensions User manual SIPLACE SX1/SX2
6.4 Tray holder From software version SC 706.1 SP1 Version 10/2014
326
6.4 Tray holder
Item no. 00141286-xx Tray holder
Item no. 00519840-xx Tape guide channel for tray holder
Components can be made available quickly on waffle pack trays with the help of the tray holder.
If the tray holder is not present, you can use all 60 feeder tracks on the SX changeover table.
To use the tray holder on an SX changeover table, you need to fit the machine with a modified
empty tape channel.
For a detailed description and operating details, refer to the " Assembly Instructions - Manual
Tray - SIPLACE SX1/SX2", Item No. 00196823-xx]
The tray holder can only be used if the relevant changeover table and its COT insert are fitted in
the outer position.
Individually placed JEDEC waffle pack trays or waffle pack magazines can be fixed to the waffle
pack tray carrier with magnets. If two JEDEC waffle pack trays are fitted, fix these into place with
the locking and fixture rails.
Parts: Item no.:
Magnet 00316593-xx
Locking bar/mounting rail for JEDEC magazines 00372615-xx
CAUTION
Avoiding collisions
When moving a component trolley in or out, make sure that the tray holder is not in place
as this could cause a collision with the empty tape channel and the nozzle changer holder.
The tray holder may only be fitted to the table once the table has been moved in.
Remove the tray holder from the table before moving the table out.
User manual SIPLACE SX1/SX2 6 Station extensions
From software version SC 706.1 SP1 Version 10/2014 6.4 Tray holder
327
6.4.1 Technical data
6
6
Occupation of locations on the component trolley in the SIPLACE SX1/
SX2
26
Configuration options in the placement machine
SIPLACE SX2
SIPLACE SX1
Locations 1 and 2
Location 1
Placement head range TwinStar, CPP
*a
*)a Only permitted in high assembly position (CPP_H).
Max. waffle pack tray height including components
MultiStar
TwinStar
11.5 mm
25 mm
PLEASE NOTE
Further information
The maximum component height for the waffle pack tray holder depends on the maxi-
mum component height for the placement head used. When using waffle pack trays,
bear in mind that the components may not higher than the pickup height of a standard
feeder.
