5 Working with the machine User manual SIPLACE SX1/SX2 5.9 Carrying out a sight check From software version SC 706.1 SP1 Version 10/2014 254 5.9 Carrying out a sight check 5.9.1 Checking the X feeder modules 5 Fig. 5.9 -…
User manual SIPLACE SX1/SX2 5 Working with the machine
From software version SC 706.1 SP1 Version 10/2014 5.8 Shift changeover
253
5.8.2 Safety instructions for emptying the waste tape container (SX1/SX2 only)
5
Fig. 5.8 - 1 Safety instructions for emptying the waste tape container
(1) Handle
(2) Waste tape container
The waste tape container must be pulled out of the component trolley for emptying. There is a risk
of catching your fingers as you do so.
To avoid this risk, hold the waste tape container with your fingers in the handle
(item 1).
Do NOT put your fingers in the gap between the tape container and waste tape container as
you could catch your fingers if you do.
(1)
(2)
5 Working with the machine User manual SIPLACE SX1/SX2
5.9 Carrying out a sight check From software version SC 706.1 SP1 Version 10/2014
254
5.9 Carrying out a sight check
5.9.1 Checking the X feeder modules
5
Fig. 5.9 - 1 Checking the X feeder modules (example of 8 mm X shown)
(1) Flap
(2) Blade
(3) Status display
(4) LCD display
5
Check to see whether the tape foil removal container for the X tape feeder module is full.
Open the flap (item 1). Pull out the cover foil and cut it with scissors or on the integral blade
(item 2) on 8 and 12 mm X tape feeder modules.
5
User manual SIPLACE SX1/SX2 5 Working with the machine
From software version SC 706.1 SP1 Version 10/2014 5.9 Carrying out a sight check
255
5
Check the multicolor status display (item 3 in fig. 5.9 - 1, page 254).
– If it lights up green, the feeder module is on standby.
– If it lights up orange, it is signaling a warning. The text of the warning
appears on the LCD display (item 4 in fig. 5.9 - 1
, page 254). The LEDs shine accordingly
for Smart Feeders.
– If the status display lights up red, a malfunction has occurred. The error message
appears on the LCD display (item 3 in fig. 5.9 - 1
, page 254). The LEDs shine accordingly
for Smart Feeders.
A list of the LCD and status displays on the operator panel is given in section 5.11
, page
270
. 5
A list of the LED and status displays on the Smart Feeder operator panel is given in sec-
tion 5.11.2
, page 271. 5
5
If the status display is off, the cause may be as follows: 5
– The feeder module is not in the current setup.
– The feeder module is defective.
– The feeder module has been disabled (due to a drop in pressure, for example)
5.9.2 Splicing the tapes in good time
5
5
CAUTION
Problems with cover foil withdrawal!
If the cover foil tears, this could lead to problems with the cover foil withdrawal.
There is an integral blade (item 2) for easily cutting the on the 8 and 12 mm X tape feeder
modules.
PLEASE NOTE
Late splicing of tapes
Late splicing of tapes can lead to prolonged down times.
Splice the tapes early enough so that the feeder modules do not run out of compo-
nents.
PLEASE NOTE
Early splicing of tapes
Early splicing of tapes can have the following consequence: when the old tape is rolled up
onto the new reel, the new reel could become too full and the tape will slide off it and get
caught up. This will again result in pick-up errors and prolonged down times.
Splice the tapes at the right time so that the old and new tapes do not get caught.
