Install Tray Unit (Including machine modification)
SHEET
71/73
WKGB-10104-03
Installing Tray Unit
(Including machine modification)
9 Close the XY Axis motion menu and display
the H Axis motion menu.
10 Lower the end of the nozzle down to
0.03[mm] from the jig by the H Axis motion
menu.
11 Remove the thickness gauge and lower the
H axis by 0.03[mm].
12 Press the Acq. Pos. button to close the H
Axis motion screen.
13 Press the Set button on the Parts Supply
screen.
Install Tray Unit (Including machine modification)
SHEET
72/73
WKGB-10104-03
Installing Tray Unit
(Including machine modification)
14 Press the emergency stop button to turn
OFF the servo.
15 Remove the jig nozzle and tray pickup
position teaching jig.
Install Tray Unit (Including machine modification)
SHEET
73/73
WKGB-10104-03
Installing Tray Unit
(Including machine modification)
[Installation of hood]
1 Install the hood bracket with the 2-CP3x10
to S axis unit.
NOTE:
Commonly use the screws fixing the guide for the
S Axis rail.
2 Install the hood with the +T4x8.
