F axis movable part
RPGB-10101-01
F Axis Belt Replacement Procedure
SHEET
1/9
F Axis Belt Replacement Procedure
[Necessary Jigs]
• Tension meter (UNITTA U-505)
• Tension jig (for G only)
[Removal]
1 Open the slide door on the front side of the main body or the slide door on the rear side of the main
body.
2 Press the head base to move it to the area in which it is easy to work with.
3 Sever the Insulock that ties the wiring down.
4 Remove the FSEN2F connector from the
relay plate.
RNFM
RTFM
HFM
FSEN2F
LEDF
RTFE
RNFE
PDF
BLKF
CSFT-LSF
CSF TF
HFE
RTSF
RNSF
VACF-2
5 Unscrew 4-C3x6 screws to remove the
cover.
Tension jig Tension meter
Cover
4-C3x6
F axis movable part
RPGB-10101-01
F Axis Belt Replacement Procedure
SHEET
2/9
6 Hold the cable bear with a cord in order not
to put a burden on wires.
7 Unscrew 4-C4x8 screws to remove the
bracket to fix the cable bear.
8 Remove the connector of the motor power
line and the encoder line from the relay
plate.
9 Push up the bracket that fixes the cable bear
and unscrew 3-C5x15 screws to remove the
F axis unit.
Cable bear
4-C4x8
3-C5x15
F axis unit
