2-14
AKHEMT-ID
Machine Information
Codes
Display Field A (Scope of Machine Information)
Display Field B (Details of Machine Information)
800d0c Maintenance Warning
Keep the machine condition.(maintenance cycle time : Designate-Checkup/Item
#2)
800d0d Maintenance Warning
Keep the machine condition.
(maintenance cycle time : Designate-Checkup/Item #3)
800d0e Maintenance Warning
Component box fi ll up warning. (notice count over)
800e01 Program Change Warning
Check the setup of machine. (program change completed)
800e02 Program Change Warning
Check the setup of machine.
(Program change completed. Run Mode changed to "PASS".)
801001 Auto Offset Teach Information
Tape pocket recog error (run continue)
801101 Nozzle diameter confi rmation
The disagreement of the nozzle diameter was detected with the linear measure.
There is a possibility of the linear measure dirt and the nozzle dirt, please
confi rm whether a different nozzle has adhered.
801201 Start Auto Head Recovery
Cpu Communication error occurred. (CPU2-CPU3)
801202 Start Auto Head Recovery
Head cam origin return action not complete. (Not CAM ORIGIN position)
801203 Start Auto Head Recovery
Head Driver communication is time out. (from cpu3 job)
801204 Start Auto Head Recovery
Nozzle change action not complete. (cam lock action NG)
801205 Start Auto Head Recovery
Head cam position return action not complete.
801206 Start Auto Head Recovery
Nozzle change action not complete. (cam free action NG)
801207 Start Auto Head Recovery
Nozzle change action not complete. (Not CAM ORIGIN position)
801208 Start Auto Head Recovery
Unselected Nozzle Drop.
801209 Start Auto Head Recovery
Component output error (Pickup error) is detected by nozzle level was position.
;Nozzle posture detection
80120a Start Auto Head Recovery
The selected nozzle was not at position. ;Nozzle posture detection
80120b Start Auto Head Recovery
Component output error (Others) is detected by nozzle level was position.
;Nozzle posture detection
0605-002
3.2 List of Machine Information
2-15
AKHEMT-ID
Machine Information
Codes
Display Field A (Scope of Machine Information)
Display Field B (Details of Machine Information)
801301 Pickup Position Feedback
Feedback value out of range. Please check feeder.
801401 Pickup Level Data
Calculated data out of range. Please check library data and offset data.
801402 Placement Level Data
Calculated data out of range. Please check library data and offset data.
801403 Data Check
The data out of the setting range is contained in the feeder offset B data of
system data. On edit screen, X/Y of the components (tape width 8mm / sending
pitch 2mm) should be set as more than -1.0mm and less than +1.0mm.
801404 Data Check
The data out of the setting range is contained in the placement level data of
component supply changed data. On edit screen, the place level of square
shape below 3216 should be set up less than +0.5mm. When the place level
exceeding 0.5mm is required, please input H data of placement data (PP data).
801501 Feeder Index Position
Production operation was interrupted in the middle of feeder index operation.
Please check a position.
801502 Feeder Index Position
The feeder carriage was returned to the home position in the middle of feeder
index operation. Please check a feeder index position.
801601 Product Restart
Restart production with semi-auto(after specifi ed step) mode.
801602 Product Restart
Restart production with warm start mode.
801603 Product Restart
Restart production with warm start mode. Machine will stop after placement
complete. Please confi rm PCB afterward.
801901 Nozzle Adjustment
Nozzle up&down action is not available.
801902 Nozzle Adjustment
Communication error.
0609-003
3.2 List of Machine Information
2-16
AKHEMT-ID
Machine Information
Codes
Display Field A (Scope of Machine Information)
Display Field B (Details of Machine Information)
801a01 Warning Operation
Product started by RUN MODE "PASS" Operation.
801a02 Warning Operation
The PCB before component placing was conveyed from X/Y table.
801a03 Warning Operation
The PCB in the middle of component placing was conveyed from X/Y table.
801a04 Warning Operation
The feeder ready button was turned on in start protection mode.
801a05 Warning Operation
Cannot alternate by external start protection.
801b01 Lightning Surge Warning
Lightning Surge Protector works; Q204.
801b02 Lightning Surge Warning
Lightning Surge Protector works; Q204. Running continue.
801c01 Information
This placement step was detected outside of the possible range. This step is
auto skip running.
801c03 Information
Data was changed during machine worked. The changed data is not refl ected
in operation until it stops or interrupts operation.
801c04 Information
PCB Origin Position data is not right. Please correct a PCB Origin Position on a
"Prod Chng (Origin Pos)" screen.
801c05 Information
Warm start mode was canceled.
801c06 Information
The machine stopped by the automatic stop function.
801c07 Information
Warm start mode was canceled. Please remove the unaccomplished PCB.
801c08 Information
It started with the data out of the setting range contained in the feeder offset B
data of system data. On edit screen, X/Y of the components (tape width 8 mm
/ sending pitch 2 mm) should be set as more than -1.0 mm and less than +1.0
mm.
801c09 Information
It started with the data out of the setting range contained in the placement level
data of component supply changed data. On edit screen, the place level of
square shape below 3216 should be set up less than +0.5 mm. When the place
level exceeding 0.5 mm is required, please input H data of placement data (PP
data).
801e01 Placement Level Data
Calculated data out of range. Please check library data and pattern program
data.
0609-003
3.2 List of Machine Information
