4-8
AKHEMT-ID
Recognition Error ID Description of Recognition Error, Cause, and Remedy
0 2 1 ** 910 Error in Recognition Communication Data
0 2 1 ** 911 Error in Recognition Communication Data
0 2 1 ** 912 Error in Recognition Communication Data
0 2 1 ** 913 Error in Recognition Communication Data
0 2 1 ** 914 Error in Recognition Communication Data
0 2 1 ** 915 Error in Recognition Communication Data
0 2 1 ** 916 Error in Recognition Communication Data
0 2 1 ** 917 Error in Recognition Communication Data
0 2 1 ** 918 Error in Recognition Communication Data
0 2 1 ** 919 Error in Recognition Communication Data
0 2 1 ** 91a Error in Recognition Communication Data
0 2 1 ** 91b Error in Recognition Communication Data
0 2 1 ** 9 1c Error in Recognition Communication Data
0 2 1 ** 91d Error in Recognition Communication Data
0 2 1 ** 91e Error in Recognition Communication Data
0 2 1 ** 9 1 f Error in Recognition Communication Data
(Cause) Recognition Communication Data Error
(Remedy) Contact our service personnel for details.
0 2 2 ** 301 "Mark Size D1" is small.
0 2 2 ** 302 "Mark Size D1" is big.
0 2 2 ** 303 "Window Size" is smaller than "Mark Size".
0 2 2 ** 304 "Mark Size D2" is big, compared with "D1".
0 2 2 ** 305 "Mark Size D2" is not set.
0 2 2 ** 501
The total of "Corner 1 Dim X" and "Corner 4 Dim X" is larger than "Mold Size
X".
0 2 2 ** 502
The total of "Corner 1 Dim Y" and "Corner 2 Dim Y" is larger than "Mold Size
Y".
0 2 2 ** 503
The total of "Corner 2 Dim X" and "Corner 3 Dim X" is larger than "Mold Size
X".
0 2 2 ** 504
The total of "Corner 3 Dim Y" and "Corner 4 Dim Y" is larger than "Mold Size
Y".
0 2 2 ** 505 Device Size is small.
0 2 2 ** 506 Device Size is big.
0 2 2 ** 507
The component cannot be recognized in the "Back Lighting" system
because the component size is big.
0 2 2 ** 508 The component's thickness is large.
0 2 2 ** 509 The number of effective corners is small.
0 2 2 ** 50a No effective combination of edges is found.
0 2 2 ** 601 "# of Groups" (lead data) is improper.
0 2 2 ** 602 The total of "# of Leads" (lead data) is small.
0 2 2 ** 603 No detection is set in all "Insp Condtn" text boxes.
(Cause) Wrong parameters are set.
(Remedy) Set correct parameters.
0602-001
3.3 Recognition Communication Errors
4-9
AKHEMT-ID
Recognition Error ID Description of Recognition Error, Cause, and Remedy
0 2 2 * * 611 "Lead Pitch" in "Lead Group 1" is smaller than "Lead Width".
0 2 2 ** 612 "Lead Pitch" in "Lead Group 2" is smaller than "Lead Width".
0 2 2 ** 613 "Lead Pitch" in "Lead Group 3" is smaller than "Lead Width".
0 2 2 ** 614 "Lead Pitch" in "Lead Group 4" is smaller than "Lead Width".
0 2 2 ** 615 "Lead Pitch" in "Lead Group 5" is smaller than "Lead Width".
0 2 2 ** 616 "Lead Pitch" in "Lead Group 6" is smaller than "Lead Width".
0 2 2 ** 617 "Lead Pitch" in "Lead Group 7" is smaller than "Lead Width".
0 2 2 ** 618 "Lead Pitch" in "Lead Group 8" is smaller than "Lead Width".
0 2 2 ** 621 "Missing Lead Start" in "Lead Group 1" is large.
0 2 2 ** 622 "Missing Lead Start" in "Lead Group 2" is large.
0 2 2 ** 623 "Missing Lead Start" in "Lead Group 3" is large.
0 2 2 ** 624 "Missing Lead Start" in "Lead Group 4" is large.
0 2 2 ** 625 "Missing Lead Start" in "Lead Group 5" is large.
0 2 2 ** 626 "Missing Lead Start" in "Lead Group 6" is large.
0 2 2 ** 627 "Missing Lead Start" in "Lead Group 7" is large.
0 2 2 ** 628 "Missing Lead Start" in "Lead Group 8" is large.
0 2 2 ** 631 "Full Length" in "Lead Group 1" is smaller than "Lead Length".
0 2 2 ** 632 "Full Length" in "Lead Group 2" is smaller than "Lead Length".
0 2 2 ** 633 "Full Length" in "Lead Group 3" is smaller than "Lead Length".
0 2 2 ** 634 "Full Length" in "Lead Group 4" is smaller than "Lead Length".
0 2 2 ** 635 "Full Length" in "Lead Group 5" is smaller than "Lead Length".
0 2 2 ** 636 "Full Length" in "Lead Group 6" is smaller than "Lead Length".
0 2 2 ** 637 "Full Length" in "Lead Group 7" is smaller than "Lead Length".
0 2 2 ** 638 "Full Length" in "Lead Group 8" is smaller than "Lead Length".
0 2 2 ** 641 "Lead Width" is small.
0 2 2 ** 642 "Lead Length" is small.
0 2 2 ** 643 "Full Length" is small.
0 2 2 ** 644 "Lead Pitch" is narrow.
0 2 2 ** 645 The lead-to-lead distances are short.
0 2 2 ** 646 The total of "# of Leads" (lead data) is large.
0 2 2 ** 701 "# of Groups" (elctd data) is improper.
0 2 2 ** 702 No detection is set in all "Insp Condtn" text boxes.
0 2 2 ** 703 Elctd # of Rows or # of Cols is improper.
0 2 2 ** 704 "Electrode" is overlapped.
(Cause) Wrong parameters are set.
(Remedy) Set correct parameters.
0602-001
3.3 Recognition Communication Errors
4-10
AKHEMT-ID
0602-001
Recognition Error ID Description of Recognition Error, Cause, and Remedy
0 2 2 * * 711 "Elctd Row or Col Pitch" in "Elctd Group 1" is smaller than "Elctd Dim".
0 2 2 ** 712 "Elctd Row or Col Pitch" in "Elctd Group 2" is smaller than "Elctd Dim".
0 2 2 ** 713 "Elctd Row or Col Pitch" in "Elctd Group 3" is smaller than "Elctd Dim".
0 2 2 ** 714 "Elctd Row or Col Pitch" in "Elctd Group 4" is smaller than "Elctd Dim".
0 2 2 ** 715 "Elctd Row or Col Pitch" in "Elctd Group 5" is smaller than "Elctd Dim".
0 2 2 ** 716 "Elctd Row or Col Pitch" in "Elctd Group 6" is smaller than "Elctd Dim".
0 2 2 ** 717 "Elctd Row or Col Pitch" in "Elctd Group 7" is smaller than "Elctd Dim".
0 2 2 ** 718 "Elctd Row or Col Pitch" in "Elctd Group 8" is smaller than "Elctd Dim".
0 2 2 ** 719 "Elctd Row or Col Pitch" in "Elctd Group 9" is smaller than "Elctd Dim".
0 2 2 ** 71A "Elctd Row or Col Pitch" in "Elctd Group 10" is smaller than "Elctd Dim".
0 2 2 ** 71B "Elctd Row or Col Pitch" in "Elctd Group 11" is smaller than "Elctd Dim".
0 2 2 ** 71C "Elctd Row or Col Pitch" in "Elctd Group 12" is smaller than "Elctd Dim".
0 2 2 ** 71D "Elctd Row or Col Pitch" in "Elctd Group 13" is smaller than "Elctd Dim".
0 2 2 ** 71E "Elctd Row or Col Pitch" in "Elctd Group 14" is smaller than "Elctd Dim".
0 2 2 ** 71F "Elctd Row or Col Pitch" in "Elctd Group 15" is smaller than "Elctd Dim".
0 2 2 ** 720 "Elctd Row or Col Pitch" in "Elctd Group 16" is smaller than "Elctd Dim".
0 2 2 ** 721 "Elctd Row or Col Pitch" in "Elctd Group 17" is smaller than "Elctd Dim".
0 2 2 ** 722 "Elctd Row or Col Pitch" in "Elctd Group 18" is smaller than "Elctd Dim".
0 2 2 ** 723 "Elctd Row or Col Pitch" in "Elctd Group 19" is smaller than "Elctd Dim".
0 2 2 ** 724 "Elctd Row or Col Pitch" in "Elctd Group 20" is smaller than "Elctd Dim".
0 2 2 ** 725 "Elctd Row or Col Pitch" in "Elctd Group 21" is smaller than "Elctd Dim".
0 2 2 ** 726 "Elctd Row or Col Pitch" in "Elctd Group 22" is smaller than "Elctd Dim".
0 2 2 ** 727 "Elctd Row or Col Pitch" in "Elctd Group 23" is smaller than "Elctd Dim".
0 2 2 ** 728 "Elctd Row or Col Pitch" in "Elctd Group 24" is smaller than "Elctd Dim".
0 2 2 ** 729 "Elctd Row or Col Pitch" in "Elctd Group 25" is smaller than "Elctd Dim".
0 2 2 ** 72A "Elctd Row or Col Pitch" in "Elctd Group 26" is smaller than "Elctd Dim".
0 2 2 ** 72B "Elctd Row or Col Pitch" in "Elctd Group 27" is smaller than "Elctd Dim".
0 2 2 ** 72C "Elctd Row or Col Pitch" in "Elctd Group 28" is smaller than "Elctd Dim".
0 2 2 ** 72D "Elctd Row or Col Pitch" in "Elctd Group 29" is smaller than "Elctd Dim".
0 2 2 ** 72E "Elctd Row or Col Pitch" in "Elctd Group 30" is smaller than "Elctd Dim"
0 2 2 ** 741 Electrode position superposed in different electrode group.
0 2 2 ** 742 "Elctd Dim" is small.
0 2 2 ** 743 "Elctd Row or Col Pitch" is narrow.
0 2 2 ** 744 The electrode-to-electrode distance is short.
(Cause) Wrong parameters are set.
(Remedy) Set correct parameters.
0602-001
3.3 Recognition Communication Errors
