3-4
AKHEMT-ID
Erroe ID Error Name, Description, Cause, and Remedy
400303 B Beam Power Shutoff
-----
400401 Interlock Error
The [emergency stop] switch was pressed. (Please confi rm the nozzle has not fallen
when you push the beam by the hand.)
Please switch on a power supply after canceling an emergency stop switch.
400402 Interlock Error
Safety cover opened.
Please shut a safety cover and push the [POWER ON] button.
400403 Interlock Error
Safety cover(CV) detected.
-----
400404 Interlock Error
Beam XY(Raer) main power off.
-----
400405 Interlock Error
Beam XY(front) main power off.
-----
400406 Interlock Error
Head (Rear) Nozzle downward detected.
The starting point must return.
400407 Interlock Error
Head (Front) Nozzle downward detected.
The starting point must return.
400408 Interlock Error
Disengaged Latch (Rear) was detected.
-----
400409 Interlock Error
Disengaged Latch (Front) was detected.
-----
40040a Interlock Error
The suppressor Mis-set (Rear) detected.
Please execute the Warm start.
40040b Interlock Error
The suppressor Mis-set (front) detected.
Please execute the Warm start.
40040c Interlock Error
Feeder peristome sensor (rear) shaded.
Please remove the factor which is shading the feeder peristome sensor (rear), and
carry out a zero return. (It continues at a warm start)
40040d Interlock Error
Feeder peristome sensor (front) shaded.
Please remove the factor which is shading the feeder peristome sensor (front), and
carry out a zero return. (It continues at a warm start)
0609-003
3.1 Safety Devices
3-5
AKHEMT-ID
Erroe ID Error Name, Description, Cause, and Remedy
40040e Interlock Error
CB Alarm XY(Rear) Detected.
-----
40040f Interlock Error
CB Alarm XY(Front) Detected.
-----
400410 Interlock Error
CB Error (Conveyor/Cutter) Detected.
-----
400411 Interlock Error
CB Alarm (CPU2) Detected.
-----
400412 Interlock Error
CB Alarm (DC24) Detected.
-----
400413 Interlock Error
Air pressure Drop Detected.
-----
400414 Interlock Error
CB Alarm (Vacuum Pump)
-----
400415 Interlock Error
The urgent stop reserve input was input.
Turning on the power supply again then the emergency stop must be pushed, and
the starting point must return later.
400416 Interlock Error
NL axis (Front) Interlock Detected. Please confi rm the nozzle has not fallen when
you push the beam by the hand.
The starting point must return. When the lock of a safety door cannot be canceled,
please push an emergency stop button. (Please confi rm the nozzle has not fallen
when you push the beam by the hand.)
400417 Interlock Error
NL axis(Rear) Interlock Detected. Please confi rm the nozzle has not fallen when
you push the beam by the hand.
The starting point must return. When the lock of a safety door cannot be canceled,
please push an emergency stop button. (Please confi rm the nozzle has not fallen
when you push the beam by the hand.)
400418 Interlock Error
L1 axis(Front) Interlock Detected. Please confi rm the nozzle has not fallen when
you push the beam by the hand.
Confi rm of Path line/Head excess pushing detection.
400419 Interlock Error
L2 axis(Front) Interlock Detected. Please confi rm the nozzle has not fallen when
you push the beam by the hand.
Confi rm of Path line/Head excess pushing detection.
0609-002
3.1 Safety Devices
3-6
AKHEMT-ID
Erroe ID Error Name, Description, Cause, and Remedy
400420 Interlock Error
L3 axis (Front) Interlock Detected. Please confi rm the nozzle has not fallen when
you push the beam by the hand.
Confi rm of Path line/Head excess pushing detection.
400421 Interlock Error
L1 axis (Rear) Interlock Detected. Please confi rm the nozzle has not fallen when
you push the beam by the hand.
Confi rm of Path line/Head excess pushing detection.
400422 Interlock Error
L2 axis (Rear) Interlock Detected. Please confi rm the nozzle has not fallen when
you push the beam by the hand.
Confi rm of Path line/Head excess pushing detection.
400423 Interlock Error
L3 axis (Rear) Interlock Detected. Please confi rm the nozzle has not fallen when
you push the beam by the hand.
Confi rm of Path line/Head excess pushing detection.
400425 Interlock Error
An emergency stop switch is pushed.
Please switch on a power supply after canceling an emergency stop switch.
400501 Lightning Surge Warning
Lightning Surge Protector works; L201,L202,L203. Please turn on the load power
supply after resetting error.
-----
400502 Lightning Surge Warning
-----
400503 Lightning Surge Warning
-----
400504 Lightning Surge Warning
-----
400505 Lightning Surge Warning
-----
400601 Servo Alarm
Servo Alarm Detected.
-----
400602 Servo Alarm
All Beam alarm reseting API Error
-----
0609-003
3.1 Safety Devices
