4-14 AKHEMT -ID Recognition Error ID Description of Recognition Error , Cause, and Remedy 0 2 D * * * * * Error in Recognition Communication Data. (Cause) An error was found in the recognition communication data. (Remedy…
4-13
AKHEMT-ID
Recognition Error ID Description of Recognition Error, Cause, and Remedy
0 2 2 ** 901 "Mold Size Tolerance X" is larger than "Mold Size X".
0 2 2 ** 902 "Mold Size Tolerance Y" is larger than "Mold Size Y".
0 2 2 ** 903 "Outward Length Tolerances" are larger than "Outward Length".
0 2 2 ** 904 "Polarity Inspection Position" out of "Mold Size"
0 2 2 ** 905 Selected algorithm is improper.
0 2 2 ** 906 Failed in automatic selection of algorithm.
(Cause) Wrong parameters are set.
(Remedy) Set correct parameters.
0 2 3 ** 001 Recognition Communication Procedure Error
0 2 3 ** 002 Recognition Communication Procedure Error
0 2 3 ** 003 Recognition Communication Procedure Error
0 2 3 ** 004 Recognition Communication Procedure Error
0 2 3 ** 005 Recognition Communication Procedure Error
0 2 3 ** 006 Recognition Communication Procedure Error
0 2 3 ** 007 Recognition Communication Procedure Error
(Cause) Recognition Communication Procedure Error
(Remedy) Contact our service personnel for details.
0 2 4 ** 001
An error occurred during data transfer between recognition and counter
boards.
(Cause) Recognition-to-Counter Board Communication Error
(Remedy) Contact our service personnel for details.
0 2 4 ** 002
An error occurred during data transfer between recognition and lighting
control boards.
(Cause) Recognition-to-Lighting Control Board Communication Error
(Remedy) Contact our service personnel for details.
0 2 4 ** 003 Lighting control board self-diagnostic abnormalities
(Cause) Lighting Control Board Self-Diagnostics Error
(Remedy) Contact our service personnel for details.
0 2 4 ** 101 The Comp. recognition lighting of beam 1 did not light.
0 2 4 ** 102 The Comp. recognition lighting of beam 2 did not light.
0 2 4 ** 103 The Comp. recognition lighting of beam 3 did not light.
0 2 4 ** 104 The Comp. recognition lighting of beam 4 did not light.
(Cause) An error was found in the component recognition lighting.
(Remedy) Contact our service personnel for details.
0 2 9 ** 001 Image Aquiring in was interrupted.
0 2 9 ** 101 Image data fi le can't be saved.
0 2 9 ** 102 Image data fi le can't be saved.
0 2 9 ** 103 Image data fi le can't be saved.
(Cause) Self-Diagnostics Error Message
(Remedy) Contact our service personnel for details.
0602-001
3.3 Recognition Communication Errors
4-14
AKHEMT-ID
Recognition Error ID Description of Recognition Error, Cause, and Remedy
0 2 D * * * * * Error in Recognition Communication Data.
(Cause) An error was found in the recognition communication data.
(Remedy) Contact our service personnel for details.
0 2 E ** *** Error in Recognition Communication Data.
(Cause) An error was found in the recognition communication data.
(Remedy) Contact our service personnel for details.
1 2 * * * * * * Error in Recognition Communication Data
(Cause) An error was found in the recognition communication data.
(Remedy) Contact our service personnel for details.
0602-001
3.3 Recognition Communication Errors
4-15
AKHEMT-ID
3.4 Component Recognition Errors
Z
A
B CC DDD
Detailed Classifi cation: Detailed Classifi cation
Small Classifi cation: Small Classifi cation
Middle Classifi cation
0: Component Recognition (Component Missing)
1: Component Recognition (Coarse Recognition Error)
2: Component Recognition (Detailed Recognition Error)
8: Component Recognition (Inspection Error)
9: Component Recognition (Judgment Error)
A: Component Recognition (Judgment Error)
E: Component Recognition (Other Errors)
Large Classifi cation (5)
Classifi cation Criteria
Notice
When an error ID other than the described ones is issued, contact
our service personnel for some advice.
Table 4D7
Recognition Error ID Description of Recognition Error, Cause, and Remedy
0 5 0 ** 001 Component was not found.
(Cause 1) Check if the feeder is loaded with components other than the
specifi ed ones (the components to be used).
(Cause 2) The vacuum suction force is too weak.
(Cause 3) An improper nozzle is selected for the components or vice versa.
(Remedy 1) Check if proper components are used.
(Remedy 2) Check the vacuum pressure.
(Remedy 3) Check the parameters in the nozzle type data and the
component library data.
0 5 1 ** 001 Component was not detected.
0 5 1 ** 101 The detection window of the length position of lead sequence can't be set
up.
0 5 1 ** 102 The length position of a lead sequence can't be detected.
0 5 1 ** 103 Impossible to set the window for lead detection at the corner.
0 5 1 ** 104 The lead edge of a corner can't be detected.
0 5 1 ** 105 The lead of a corner can't be detected.
0 5 1 ** 106 Few lead numbers of the detected corner than the setup.
0 5 1 ** 107 The distance during the lead of the detected corner is poor.
0 5 1 ** 108 The angle during the lead of the detected corner is poor.
0 5 1 ** 201 No Electrode (ball) Detected.
(Cause) Component Recognition Error
(Remedy) Contact our service personnel for details.
0602-001
3.4 Component Recognition Errors
